40 Gbps Breakout Ports
The following example checks for ports with active breakout configuration and then removes breakout
from ports 1/3/1 through 1/3/6.
Device# show breakout
Unit-Id: 1
Port
1/1/5
1/1/6
1/1/7
1/1/8
1/1/9
1/1/10
1/1/11
1/1/12
1/1/13
1/1/14
1/1/15
1/1/16
1/2/1
1/2/2
1/2/3
1/2/4
1/2/5
1/2/6
1/3/1
1/3/2
1/3/3
1/3/4
1/3/5
1/3/6
Device# configure terminal
Device(config)# no breakout ethernet 1/3/1 to 1/3/6
Reload required.
Device(config)# write memory
Write startup-config done.
Device(config)# Flash Memory Write (8192 bytes per dot) .
Copy Done.
Device(config)# end
Device# reload
NOTE
If there had been any configuration on any sub-ports (1/3/1:1 to 1/3/6:4), the no
breakout command would have returned an error. The configuration would
then have to be removed from the sub-ports before breakout configuration
could be removed.
The following example shows a failed attempt to remove breakout from port
1/1/5 as indicated by the error message. Configuration is then removed from
sub-port 1/1/5:1 before the breakout configuration is successfully removed.
Once the updated configuration is loaded, the ports are restored as full 40 Gbps
ports. The former sub-port configuration is not retained in memory.
device(config)# no breakout ethernet 1/1/5
Error: Port 1/1/5:1 is tagged
device(config)# vlan 200
device(config-vlan-200)# no tagged ethernet 1/1/5:1
Deleted tagged port(s) to port-vlan 200.
device(config)# end
device# configure terminal
device(config)# no breakout ethernet 1/1/5
Reload required.
device(config)# end
device# write memory
Write startup-config done.
382
Module Exist Module Conf
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Please write memory and then reload or power cycle.
Please write memory and then reload or power cycle.
breakout_conf breakout_oper
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
