Field
Neighbor entries aged out
Neighbor advertisements
dropped
Port
Tx Pkts Total
Rx Pkts Total
Rx Pkts w/Errors
Rx Pkts Discarded
Rx TLVs Unrecognz
Rx TLVs Discarded
Neighbors Aged Out

Displaying LLDP neighbors

The show lldp neighbors command displays a list of the current LLDP neighbors per port.
The following shows an example report.
device#show lldp neighbors
Lcl Port Chassis ID
1
1
3
4
4
15
16
17
18
Syntax:show lldp neighbors
The following table describes the information displayed by the show lldp neighbors command.
FastIron Ethernet Switch Administration Guide
53-1003625-01
Description
The number of LLDP neighbors dropped on all ports after the time-to-live expired.
Note that LLDP entries age out naturally when a port cable or module is
disconnected or when a port becomes disabled. However, if a disabled port is re-
enabled, the system will delete the old LLDP entries.
The number of valid LLDP neighbors the device detected, but could not add. This
can occur, for example, when a new neighbor is detected and the device is already
supporting the maximum number of neighbors possible. This can also occur when
an LLDPDU is missing a mandatory TLV or is not formatted correctly.
The local port number.
The number of LLDP packets the port transmitted.
The number of LLDP packets the port received.
The number of LLDP packets the port received that have one or more detectable
errors.
The number of LLDP packets the port received then discarded.
The number of TLVs the port received that were not recognized by the LLDP local
agent. Unrecognized TLVs are retained by the system and can be viewed in the
output of the show LLDP neighbors detail command or retrieved through SNMP.
The number of TLVs the port received then discarded.
The number of times a neighbor information was deleted because its TTL timer
expired.
Port ID
0000.0034.0fc0 0000.0034.0fc0
0000.0001.4000 0000.0001.4000
0000.0011.0200 0000.0011.0203
0000.0011.0200 0000.0011.0202
0000.0011.0200 0000.0011.0210
0000.0011.0200 0000.0011.020f
0000.0011.0200 0000.0011.020e
0000.0011.0200 0000.0011.0211
0000.0011.0200 0000.0011.0210
Displaying LLDP neighbors
Port Description
GigabitEthernet9/1
GigabitEthernet0/1/1
GigabitEthernet4
GigabitEthernet3
GigabitEthernet17
GigabitEthernet16
GigabitEthernet15
GigabitEthernet18
GigabitEthernet17
System Name
FastIron Supe~
FastIron SX Swi~
FastIron SX 8~
FastIron SX 8~
FastIron SX 8~
FastIron SX 8~
FastIron SX 8~
FastIron SX 8~
FastIron SX 8~
211
