Viewing egress queue counters on ICX 6610 and FCX devices

Known Unicast
Multicast & Unknown Unicast : 2752
Broadcast
Dropped Frames:
Bridge Egress Filtered
Congestion Drops
Syntax: show transmit-counter values number
where number identifies a valid enhanced traffic counter and is a value from 1 - 64.
TABLE 34
This line...
Transmitted frames
Known Unicast
Multicast & Unknown
Unicast
Broadcast
Dropped Frames
Bridge Egress Filtered
Congestion Drops
Viewing egress queue counters on ICX 6610 and FCX devices
The show interface command displays the number of packets on a port that were queued for each
QoS priority (traffic class) and dropped because of congestion.
NOTE
These counters do not include traffic on management ports or for a stack member unit that is down.
The egress queue counters display at the end of the show interface command output as shown in the
following example.
device#show interface e 1/1/1
GigabitEthernet1/1/1 is up, line protocol is up
Hardware is GigabitEthernet, address is 0000.0077.8080 (bia 0000.0077.8080)
238
: 124
: 0
: 37
: 0
Outbound traffic counter statistics
Displays...
The number of known unicast packets transmitted.
The number of multicast and unknown unicast packets transmitted.
The number of broadcast packets transmitted.
The number of bridged outbound packets that were filtered and dropped.
This number includes the number of packets that were dropped because of any one of
the following conditions:
• The port was disabled or the link was down.
• The port or port region does not belong to the VLAN specified in the transmit
counter configuration.
• A Layer 2 protocol (e.g., spanning tree) had the port in a Blocked state.
• The source port was suppressed for multi-target packets.
• The priority queue specified in the traffic counter was not allowed for some other
reason.
• Unknown unicast and unregistered multicast packets were filtered.
The number of outbound packets that were dropped because of traffic congestion.
