Displaying detailed information about PoE power supplies

TABLE 44
Column
Total PD Power
Switched to PSE
Port
Oper State
Oper Mode
Fault/Error
Displaying detailed information about PoE power supplies
The show inline power detail command displays detailed operational information about the PoE
power supplies in FastIron PoE switches. The command output differs on FCX POE+ switches
compared to FSX Series and ICX switches.
The following is an example of the show inline power detail command output on an FCX POE+
switch.
device# show inline power detail
Power Supply Data On stack 1:
++++++++++++++++++
Power Supply #1:
POE Details Info. On Stack 1 :
General PoE Data:
+++++++++++++++++
Firmware
Version
--------
02.1.0
Cumulative Port State Data:
+++++++++++++++++++++++++++
#Ports
Admin-On
-------------------------------------------------------------------------
45
Cumulative Port Power Data:
+++++++++++++++++++++++++++
#Ports
Pri: 1
-----------------------------------------------
0
Power Supply Data On stack 2:
364
Field definitions for the show inline power pd command (Continued)
Definition
Total PD power switched to PSE. It is either 0 or the total available power.
The port number of the PD port.
The operational state of the PD port. This value can be one of the following:
• On - The PD port is linked to a PSE port and is consuming power.
• Off - The PD port is not linked to a PSE port and is not consuming power.
The operational mode of the PD port. This value is meaningful if Oper State is On. This
value can be one of the following:
• 802.3af - The PD port is operating in the AF mode.
• 802.3at - The PD port is operating in the AT mode.
• n/a - The PD port is not operational.
Shows the error or fault conditions affecting the PD port. This value can be one of the
following:
• An error or fault code is displayed.
• n/a - No error or fault condition on the PD port.
Max Curr: 7.5 Amps
Voltage: 54.0 Volts
Capacity: 410 Watts
#Ports #Ports #Ports
Admin-Off Oper-On Oper-Off
3 0 48
#Ports #Ports Power
Pri: 2 Pri: 3 Consumption
0 45 0.0
#Ports #Ports
Off-Denied Off-No-PD
0 45
Power
Allocation
W 0.0 W
FastIron Ethernet Switch Administration Guide
#Ports
Off-Fault
0
