LLDP and LLDP-MED
+ Link aggregation: not capable
+ Maximum frame size: 1522 octets
+ MED capabilities: capabilities, networkPolicy, location, extendedPSE
+ MED Network Policy
+ MED Network Policy
+ MED Location ID
+ MED Location ID
+ MED Location ID
+ MED Extended Power via MDI
+ Management address (IPv4): 10.1.1.121
+ VLAN name (VLAN 99): "Voice-VLAN-99"
NOTE
The contents of the show output will vary depending on which TLVs are configured to be advertised.
A backslash (\) at the end of a line indicates that the text continues on the next line.
The fields in the above output are described in the individual TLV advertisement sections in this
chapter.
Syntax: show lldp local-info [ ports ethernet port-list | all ]
If you do not specify any ports or use the keyword all , by default, the report will show the local
information advertisements for all ports.
214
MED device type : Network Connectivity
Application Type : Voice
Policy Flags : Known Policy, Tagged
VLAN ID : 99
L2 Priority : 3
DSCP Value : 22
Application Type : Video Conferencing
Policy Flags : Known Policy, Tagged
VLAN ID : 100
L2 Priority : 5
DSCP Value : 10
Data Format: Coordinate-based location
Latitude Resolution : 20 bits
Latitude Value : -78.303 degrees
Longitude Resolution : 18 bits
Longitude Value : 34.27 degrees
Altitude Resolution : 16 bits
Altitude Value : 50. meters
Datum : WGS 84
Data Format: Civic Address
Location of: Client
Country : "US"
CA Type : 1
CA Value : "CA"
CA Type : 3
CA Value : "Santa Clara"
CA Type : 6
CA Value : "4980 Great America Pkwy."
CA Type : 24
CA Value : "95054"
CA Type : 27
CA Value : "5"
CA Type : 28
CA Value : "551"
CA Type : 29
CA Value : "office"
CA Type : 23
CA Value : "John Doe"
Data Format: ECS ELIN
Value : "1234567890"
Power Type : PSE device
Power Source : Unknown Power Source
Power Priority : Low (3)
Power Value : 6.5 watts (PSE equivalent: 7005 mWatts) + Port VLAN ID: 99
