Clearing the egress queue counters

Member of L2 VLAN ID 1, port is untagged, port state is BLOCKING
BPDU guard is Disabled, ROOT protect is Disabled, Designated protect is Disabled
Link Error Dampening is Disabled
STP configured to ON, priority is level0, mac-learning is enabled
Flow Control is enabled
Mirror disabled, Monitor disabled
Mac-notification is disabled
Not member of any active trunks
Not member of any configured trunks
No port name
IPG MII 96 bits-time, IPG GMII 96 bits-time
MTU 1500 bytes
300 second input rate: 0 bits/sec, 0 packets/sec, 0.00% utilization
300 second output rate: 0 bits/sec, 0 packets/sec, 0.00% utilization
0 packets input, 0 bytes, 0 no buffer
Received 0 broadcasts, 0 multicasts, 0 unicasts
0 input errors, 0 CRC, 0 frame, 0 ignored
0 runts, 0 giants
0 packets output, 0 bytes, 0 underruns
Transmitted 0 broadcasts, 0 multicasts, 0 unicasts
0 output errors, 0 collisions
Relay Agent Information option: Disabled
Egress queues:
Queue counters
Clearing the egress queue counters
You can clear egress queue statistics (reset them to zero), using the clear statistics and clear
statistics ethernet port command.
Syntax: clear statistics [ ethernet port]
Specify the port variable in the format stack-unit/slotnum/portnum.

RMON support

The Brocade RMON agent supports the following groups. The group numbers come from the RMON
specification (RFC 1757):
NOTE
RFC 1757 is obsolete and is replaced by RFC 2819 for the Brocade ICX devices.
• Statistics (RMON Group 1)
• History (RMON Group 2)
• Alarms (RMON Group 3)
• Events (RMON Group 9)
The CLI allows you to make configuration changes to the control data for these groups, but you need a
separate RMON application to view and display the data graphically.
240
Queued packets
0 0
1 0
2 0
3 0
4 0
5 0
6 0
7 0
Dropped Packets
0
0
0
0
0
0
0
0
