Displaying LLDP statistics and configuration settings

You can use the following CLI show commands to display information about LLDP settings and
statistics:
• show lldp - Displays a summary of the LLDP configuration settings.
• show lldp statistics - Displays LLDP global and per-port statistics.
• show lldp neighbors - Displays a list of the current LLDP neighbors.
• show lldp neighbors detail - Displays the details of the latest advertisements received from LLDP
neighbors.
• show lldp local-info - Displays the details of the LLDP advertisements that will be transmitted on
each port.
This above show commands are described in this section.

LLDP configuration summary

To display a summary of the LLDP configuration settings on the device, enter the show lldp command
at any level of the CLI.
The following shows an example report.
device#show lldp
LLDP transmit interval
LLDP transmit hold multiplier
LLDP transmit delay
LLDP SNMP notification interval
LLDP reinitialize delay
LLDP-MED fast start repeat count : 3
LLDP maximum neighbors
LLDP maximum neighbors per port
Syntax: show lldp
The following table describes the information displayed by the show lldp statistics command.
Field
LLDP transmit interval
LLDP transmit hold
multiplier
LLDP transmit delay
LLDP SNMP
notification interval
LLDP reinitialize delay
LLDP-MED fast start
repeat count
FastIron Ethernet Switch Administration Guide
53-1003625-01
Displaying LLDP statistics and configuration settings
: 10 seconds
: 4 (transmit TTL: 40 seconds)
: 1 seconds
: 5 seconds
: 1 seconds
: 392
: 4
Description
The number of seconds between regular LLDP packet transmissions.
The multiplier used to compute the actual time-to-live (TTL) value of an LLDP
advertisement. The TTL value is the transmit interval multiplied by the transmit hold
multiplier.
The number of seconds the LLDP agent will wait after transmitting an LLDP frame and
before transmitting another LLDP frame.
The number of seconds between transmission of SNMP LLDP traps
(lldpRemTablesChange) and SNMP LLDP-MED traps
(lldpXMedTopologyChangeDetected).
The minimum number of seconds the device will wait from when LLDP is disabled on a
port, until a request to re-enable LLDP on that port will be honored.
The number of seconds between LLDP frame transmissions when an LLDP-MED
Endpoint is newly detected.
