Viewing optical transceiver thresholds
TABLE 30
Field
Temperature
Tx Power
Rx Power
Tx Bias Current • The transmit bias power signal, in milliamperes (mA).
For Temperature, Tx Power, Rx Power, and Tx Bias Current in the show optic command output,
values are displayed along with one of the following alarm status values: Low-Alarm, Low-Warn,
Normal, High-Warn or High-Alarm. The thresholds that determine these status values are set by the
manufacturer of the optical transceivers. The following table describes each of these status values.
TABLE 31
Status value Description
Low-Alarm
Low-Warn
Normal
High-Warn
High-Alarm
Viewing optical transceiver thresholds
The thresholds that determine the alarm status values for an optical transceiver are set by the
manufacturer of the XFP, SFP, or SFP+. To view the thresholds for a qualified optical transceiver in a
particular port, use the show optic threshold command as shown below.
device>show optic threshold 2/2
Port 2/2 sfp monitor thresholds:
Temperature High alarm
Temperature Low alarm
Temperature High warning
Temperature Low warning
Supply Voltage High alarm
224
Output from the show optic command (Continued)
Description
• The operating temperature, in degrees Celsius, of the optical transceiver.
• The alarm status, as described in the next table.
• The transmit power signal, in decibels (dB), of the measured power referenced to one milliwatt
(mW).
• The alarm status, as described in the next table.
• The receive power signal, in decibels (dB), of the measured power referenced to one milliwatt
(mW).
• The alarm status, as described in the next table.
• The alarm status, as described in the next table.
Alarm status value description
Monitored level has dropped below the "low-alarm" threshold set by the manufacturer of the optical
transceiver.
Monitored level has dropped below the "low-warn" threshold set by the manufacturer of the optical
transceiver.
Monitored level is within the "normal" range set by the manufacturer of the optical transceiver.
Monitored level has climbed above the "high-warn" threshold set by the manufacturer of the optical
transceiver.
Monitored level has climbed above the "high-alarm" threshold set by the manufacturer of the
optical transceiver.
5a00 90.0000 C
d300 -45.0000 C
5500 85.0000 C
d800 -40.0000 C
9088
