Brocade Communications Systems FastIron Administration Manual page 347

TABLE 41
Product
FCX
ICX 64xx
ICX 6450-C12
ICX 6610
ICX 7250
ICX 7450
Installing PoE firmware with TFTP
PoE firmware is stored in the PoE controller of the FastIron switch. You can install PoE firmware from
the TFTP server on a FastIron switch using CLI commands. To do so, you should have a valid firmware
image on the TFTP server.
NOTE
The PoE firmware upgrade feature is not supported in FIPS mode on Brocade devices.
NOTE
You can install PoE firmware only on one switch at a time. To install PoE firmware on stacked units, you
need to install it individually on every switch in the stack.
NOTE
The CLI syntax to install PoE firmware is different on FSX, FCX, and ICX platforms.
NOTE
Installation of PoE firmware interrupts PoE services on the individual device or module as it is
upgraded. PoE service restarts once PoE firmware installation is complete.
1. Place the PoE firmware on a TFTP server to which the Brocade device has access.
2. Copy the PoE firmware from the TFTP server into the switch as shown in the following examples. Be
sure to use the correct file image for the platform.
To install PoE firmware on FCX and ICX platforms, use the inline power install-firmware stack-
unit command as shown in the following example.
device# inline power install-firmware stack-unit 1
fcx_poeplus_07400.fw
Syntax: inline power install-firmware [stack-unit |unit-number] tftp ip-address filename
FastIron Ethernet Switch Administration Guide
53-1003625-01
PoE Firmware files (Continued)
Installing PoE firmware with TFTP
PoE Firmware
fcx_poeplus_02.1.0.b004.fw
icx64xx_poeplus_02.1.0.b004.fw
icx64xxc12_poeplus_02.03.09.fw
fcx_poeplus_02.1.0.b004.fw
icx72xx_poeplus_01.6.1.b009.fw
icx74xx_poh_01.6.1.b009.fw
tftp 10.120.54.161
347
