Viewing Egress Queue Counters On Icx 7750 Devices - Brocade Communications Systems FastIron Administration Manual

Configured speed auto, actual 1Gbit, configured duplex fdx, actual fdx
Configured mdi mode AUTO, actual none
Member of L2 VLAN ID 52, port is untagged, port state is FORWARDING
BPDU guard is Disabled, ROOT protect is Disabled
Link Error Dampening is Disabled
STP configured to ON, priority is level0, mac-learning is enabled
Flow Control is config enabled, oper enabled, negotiation disabled
mirror disabled, monitor disabled
Not member of any active trunks
Not member of any configured trunks
No port name
Inter-Packet Gap (IPG) is 96 bit times
IP MTU 1500 bytes
300 second input rate: 0 bits/sec, 0 packets/sec, 0.00% utilization
300 second output rate: 256 bits/sec, 0 packets/sec, 0.00% utilization
0 packets input, 0 bytes, 0 no buffer
Received 0 broadcasts, 0 multicasts, 0 unicasts
0 input errors, 0 CRC, 0 frame, 0 ignored
0 runts, 0 giants
215704 packets output, 13805066 bytes, 0 underruns
Transmitted 0 broadcasts, 215704 multicasts, 0 unicasts
0 output errors, 0 collisions
Relay Agent Information option: Disabled
Egress queues:
Queue counters
Syntax: show interface [ ethernet port]
Specify the port variable in the format stack-unit/slotnum/portnum.
TABLE 35
Parameter
Queue counters
Queued packets
Dropped packets

Viewing egress queue counters on ICX 7750 devices

Viewing egress queue counters on ICX 7750 devices.
For a port, the show interface command displays the number of packets that were queued for each
QoS priority (traffic class) and dropped because of congestion. The egress queue counters are
displayed at the end of the show interface command output as shown in the following example.
NOTE
This command output displays the total of unicast and multicast counters for any particular QOS priority.
Brocade# show interface ethernet 1/1/1
10GigabitEthernet 1/1/1 is down, line protocol is down
Port down for 16 hours 16 minutes 48 seconds
Hardware is
Interface type is 40Gig Fiber
Configured speed 40Gbit, actual unknown, configured duplex fdx, actual unknown
Configured mdi mode AUTO, actual unknown
FastIron Ethernet Switch Administration Guide
53-1003625-01
Queued packets
0 0
1 0
2 1
3 0
4 0
5 0
6 0
7 215703
Egress queue statistics
Description
The QoS traffic class.
The number of packets queued on the port for the given traffic class.
The number of packets for the given traffic class that were dropped because of congestion.
10GigabitEthernet , address is 748e.f8f9.6280 (bia 748e.f8f9.6280)
Viewing egress queue counters on ICX 7750 devices
Dropped Packets
0
0
0
0
0
0
0
0
239
