A backslash (\) at the end of a line indicates that the text continues on the next line.
Except for the following field, the fields in the above output are described in the individual TLV
advertisement sections in this chapter.
Field
Neighbor The source MAC address from which the packet was received, and the remaining TTL for the neighbor
Syntax: show lldp neighbors detail [ ports ethernet port-list | all ]
If you do not specify any ports or use the keyword all , by default, the report will show the LLDP
neighbor details for all ports.

Displaying LLDP configuration details

The show lldp local-info command displays the local information advertisements (TLVs) that will be
transmitted by the LLDP agent.
NOTE
The show lldp local-info output will vary based on LLDP configuration settings.
The following shows an example report.
device#show lldp local-info ports e 20
Local port: 20
+ Chassis ID (MAC address): 0000.0033.e2c0
+ Port ID (MAC address): 0000.0033.e2d3
+ Time to live: 40 seconds
+ System name: "FCX624SHPOE-ADV Router"
+ Port description: "GigabitEthernet20"
+ System description
Inc.
FCX_ADV_ROUTER_SOFT_PACKAGE,
as
+ System capabilities : bridge
+ 802.3 MAC/PHY
+ 802.3 Power via MDI: PSE port, power enabled, class 2
FastIron Ethernet Switch Administration Guide
53-1003625-01
VLAN ID : 300
L2 Priority : 7
DSCP Value : 7
+ MED Extended Power via MDI
Power Type : PD device
Power Source : Unknown Power Source
Power Priority : High (2)
Power Value : 6.2 watts (PSE equivalent: 6656 mWatts)
+ MED Hardware revision : "PCB Version: 2"
+ MED Firmware revision : "Boot 02.01.00.11"
+ MED Software revision : "Main 02.01.00.11"
+ MED Serial number
+ MED Manufacturer
+ MED Model name
+ MED Asset ID
Description
entry.
: "Brocade Communications,
IronWare Version 07.3.00T7f3 compiled on Sep 26 2011 at 21:15:14 labeled
Enabled capabilities: bridge
: auto-negotiation enabled
Advertised capabilities: 10BaseT-HD, 10BaseT-FD, 100BaseTX-HD,
Operational MAU type: 100BaseTX-FD
Power Pair : A (not controllable)
: ""
: "Mitel Corporation"
: "MITEL 5235 DM"
: ""
100BaseTX-FD, fdxSPause, fdxBPause, 1000BaseT-HD,
1000BaseT-FD
Displaying LLDP configuration details
FCXR07300"
