HARDWARE INSTALLATION GUIDE
Brocade FastIron GS and GS-STK Hardware
Installation Guide
Part Number: 53-1002186-03
Publication Date: 15 June 2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FastIron FGS624P and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Brocade Communications Systems FastIron FGS624P

  • Page 1 HARDWARE INSTALLATION GUIDE Brocade FastIron GS and GS-STK Hardware Installation Guide Part Number: 53-1002186-03 Publication Date: 15 June 2017...
  • Page 2 The authors and Brocade Communications Systems, Inc. assume no liability or responsibility to any person or entity with respect to the accuracy of this document or any loss, cost, liability, or damages arising from the information contained herein or the computer programs that accompany it.
  • Page 3: Table Of Contents

    Contents Preface Document conventions ....................7 Text formatting conventions .
  • Page 4 ................. 46 Verifying proper operation .
  • Page 5 ................82 Power supply specifications .
  • Page 6 Cautions and Warnings ....................109 Cautions .
  • Page 7: Preface

    Preface • Document conventions ................7 •...
  • Page 8: Notes, Cautions, And Warnings

    Preface Brocade resources { x | y | z } A choice of required parameters is enclosed in curly brackets separated by vertical bars. You must select one of the options. In Fibre Channel products, square brackets may be used instead for this purpose. x | y A vertical bar separates mutually exclusive elements.
  • Page 9: Contacting Brocade Technical Support

    Preface Contacting Brocade Technical Support Contacting Brocade Technical Support As a Brocade customer, you can contact Brocade Technical Support 24x7 online, by telephone, or by e-mail. Brocade OEM customers contact their OEM/Solutions provider. Brocade customers For product support information and the latest information on contacting the Technical Assistance Center, go to http://www.brocade.com/services-support/index.html.
  • Page 10 Preface Document feedback Brocade FastIron GS and GS-STK Hardware Installation Guide Part Number: 53-1002186-03...
  • Page 11: About This Document

    About this Document • What’s new in this document ................11 What’s new in this document There is no enhancements in this edition.
  • Page 12 About this Document What’s new in this document Brocade FastIron GS and GS-STK Hardware Installation Guide Part Number: 53-1002186-03...
  • Page 13: Product Overview

    Product Overview Product overview TABLE 1 FastIron GS and GS-STK Models Standard Models Stackable Models FGS624P FGS624P-STK 24 port device, POE and stacking upgradeable 24 port stackable device, POE upgradeable FGS648P FGS648P-STK 48 port device, POE and stacking upgradeable 48 port stackable device, POE upgradeable FGS624P-DC FGS624P-DC-STK 24 port DC device, POE and stacking upgradeable...
  • Page 14: Poe Applications

    Product Overview POE applications TABLE 2 Stacking Upgrade Kits for FGS Devices FGS Upgrade Kits with Kit contents: • CX4 Module: Electrostatic Discharge (ESD) protection kit • FGS624-STK-CXU One 2-port 10GbE CX4 module • 256 MB memory DIMM FGS648-STK-CXU • Stacking EEPROM •...
  • Page 15: Hardware Features

    Product Overview Hardware features Hardware features This section describes the physical characteristics of the Brocade FGS and FGS-STK models. For details about physical dimensions, power supply specifications, and pinouts, refer to “Hardware Specifications” on page 67. FGS624P and FGS624P-POE devices FGS624P devices are POE-upgradeable.
  • Page 16: Fgs648P And Fgs648P-Poe Devices

    Product Overview Hardware features FIGURE 2 FGS624XGP and FGS624XGP-POE Devices S lo t 1 S lo t 3 F G S -2 FGS624XGP and FGS624XGP-POE models contain the following ports: • 24 10/100/1000 copper ports that support 100Base-TX and 1000Base-T RJ-45 connectors. •...
  • Page 17: Control Features

    Product Overview Hardware features FIGURE 3 FGS648P and FGS648P-POE Devices F G S -2 FGS648P and FGS648P-POE models contain the following ports: • 48 10/100/1000 copper ports that support 100Base-TX and 1000Base-T RJ-45 connectors • Four 100/1000 Gigabit Fiber uplink ports (1F – 4F) for mini-GBIC (SFP) MSA-compliant optical transceivers NOTE Copper ports 1 –...
  • Page 18 Product Overview Hardware features FIGURE 4 FGS624P and FGS624P-POE front panel Stack Lnk-Act Console Even 5 6 7 8 PS1 PS2 Pwr FGS-2XGC Gigabit Ethernet ports 1-4 Optional 2-port 10 Gbps module, ports 25 and 26 Gigabit Ethernet copper ports 1-24 FIGURE 5 FGS624P-STK and FGS624P-POE-STK Front Panel Stack...
  • Page 19: Network Interfaces

    Product Overview Hardware features FIGURE 7 FGS648P-STK and FGS648P-POE-STK Front Panel Stack Lnk-Act Console Even 5 6 7 8 PS1 PS2 Pwr Gigabit fiber ports 1F-4F Optional 2-port 10 Gigabit Ethernet module, ports 49 and 50 Gigabit Ethernet copper ports 1-48 FIGURE 8 FGS624XGP and FGS624XGP-POE Front Panel Stack...
  • Page 20 Product Overview Hardware features TABLE 3 Network Interfaces Interface Show Media Description 1000Base-BX-D M-GBXD 1000Base-BX-U M-GBXU 1000Base-LHA M-LHA 1000Base-LHB M-LHB 1000Base-LX M-LX 1000Base-SX M-SX 1000Base-SX2 M-SX2 1000Base-T 100Base-BX M-FBX 100Base-FX M-FX 10GBase-ER XG-ER 10GBase-LR XG-LR 10GBase-SR XG-SR 10GBase-ZR XG-ZR 10GBase-ZRD XG-ZRD CX4 10GbE module 10GbE XFP and CX4 module...
  • Page 21 Product Overview Hardware features Combination ports Copper ports 1 – 4 and fiber ports 1F – 4F are combination ports, meaning either the copper port or its corresponding fiber port can be active, but both cannot be active at the same time. You can use a combination of fiber and copper ports, all four copper, or all four fiber ports, as needed.
  • Page 22 Product Overview Hardware features FIGURE 11 10 Gbps 2-Port CX4 Module When this module is installed, the show media command returns the following display: FGS648 Switch# show media 0/2/1:CX4 0/2/2:CX4 2-port 10 Gbps hybrid interface module The 2-port 10 Gbps hybrid interface module (part number FGS-1XG1XGC) contains a CX4 port and an XFP port. You can order the device with one a 2-port hybrid module installed at the factory, or you can upgrade your device.
  • Page 23: Leds For Network Interfaces And Power Supplies

    Product Overview Hardware features • Recommended CX4 cable: Manufactured by WL Gore, part number IBN6600-15, CX4 Assembly - 26AWG SPC 15.0m CX4 10Gbps XFP transceiver FGS devices support a twin-axial 10G copper CX4 XFP transceiver that can be installed in any 10G port. NOTE For a link to operate properly, both sides must use identical CX4 transceivers.
  • Page 24 Product Overview Hardware features • The 100/1000 fiber ports (1F – 4F) use the LEDs located beneath the fiber connectors. These are combined Link or Activity (Lnk or Act) LEDs. • The POE ports (1 – 24) use the round LEDs located beneath the copper ports. The first (left-most) LED is for port 1, the second LED is for port 2, the third LED is for port 3, and so forth.
  • Page 25: Power Supplies

    Product Overview Hardware features TABLE 4 LEDs (Continued) Position State Meaning Left-most LED Power supply 1 is installed and is functioning beneath the console normally. Power supply 1 is located in the port right-hand bay (when you are facing the rear of the device).
  • Page 26 Product Overview Hardware features FIGURE 16 RPSDC-FGS DC power supply front panel The power supplies are auto-sensing and auto-switching, and provide 600 watts of total output power, including +12VDC @ 10A to the system and -48VDC@ 10A for Power over Ethernet applications. The power supplies provide 100-240 VAC input, 50-60Hz @ 8A to 3.2A.
  • Page 27: Cooling System And Fans

    Product Overview Hardware features Brocade 48-volt power supplies provide power to the POE daughter card, and ultimately to POE power-consuming devices. The number of POE power-consuming devices that one 48-volt power supply can support depends on the number of watts required by each device.
  • Page 28 Product Overview Hardware features Brocade FastIron GS and GS-STK Hardware Installation Guide Part Number: 53-1002186-03...
  • Page 29: Installing Fastiron Gs And Fastiron Gs-Stk Devices

    Installing FastIron GS and FastIron GS-STK Devices The procedures in this manual are intended for qualified service personnel. Unpacking a system TInformation about configuring IP addresses and connecting network devices is in the chapter “Connecting Network Devices and Checking Connectivity” on page 61.
  • Page 30: Installation Precautions

    Installing FastIron GS and FastIron GS-STK Devices Installation precautions TABLE 1 Summary of Installation Tasks Task Task Where to Find More Information Ensure that the physical environment where the device will be installed has the “Preparing the installation site” on page 33 proper cabling and ventilation.
  • Page 31: Lifting Precautions

    Installing FastIron GS and FastIron GS-STK Devices Installation precautions ° Do not install the device in an environment where the operating ambient temperature might exceed 40 ° (104 Make sure that air flow around the front, sides, and back of the device is not restricted. Never leavec tools inside the device.
  • Page 32 Installing FastIron GS and FastIron GS-STK Devices Installation precautions Ensure that the device does not overload the power circuits, wiring, and over-current protection. To determine the possibility of overloading the supply circuits, add the ampere (amp) ratings of all devices installed on the same circuit as the device.
  • Page 33: Preparing The Installation Site

    Installing FastIron GS and FastIron GS-STK Devices Preparing the installation site The FGS power supply is designed exclusively for use with the FGS devices. The power supply produces extensive power to support 802.3af applications. Installing the power supply in a device other than the FGS will cause extensive damage to your equipment.
  • Page 34: Installation Location

    Installing FastIron GS and FastIron GS-STK Devices Installing a redundant power supply Installation location Before installing the device, plan its location and orientation relative to other devices and equipment. Allow at least 7.62cm (3 inches) of space at the front of the device for the twisted-pair, fiber-optic, and power cabling. Also, allow a minimum of 3 in. of space between the sides and the back of the device and walls or other obstructions.
  • Page 35 Installing FastIron GS and FastIron GS-STK Devices Installing a redundant power supply FIGURE 2 Power supply locking screw, latches, and cover plate Cover plate Cover plate latches Power supply locking screw Remove the new power supply from the packaging. With one hand, hold the bar on the front panel of the power supply. Use your other hand to support the underside of the power supply while you insert it into the empty slot.
  • Page 36: Installing A Dc Power Supply

    Installing FastIron GS and FastIron GS-STK Devices Installing a redundant power supply Replace the power supply locking screw. Install the power cord, and secure it wIth the retaining bail, as shown in Figure NOTE The edges of the power supply panels will extend approximately .25 in.beyond the side of the device. FIGURE 4 Installing the AC power cord Cord retaining bail...
  • Page 37 Installing FastIron GS and FastIron GS-STK Devices Installing a redundant power supply If necessary, before installing a power supply, remove the power supply locking screw located in the center rear of the device, and remove the cover plate (illustrated in Figure 6 on an AC device).
  • Page 38 Installing FastIron GS and FastIron GS-STK Devices Installing a redundant power supply FIGURE 7 Inserting the DC power supply FIGURE 8 Engaging the DC power supply connectors Power supply Connectors Press the two latches on the supply outward to lock the supply in place. If you removed the receptacle for the positive and negative terminals, re-position it and secure the screws.
  • Page 39 Installing FastIron GS and FastIron GS-STK Devices Installing a redundant power supply FIGURE 9 DC power supply connector Negative terminal screw Positive terminal screw 48 RTN lead -48 VDC lead 10 AWG wire Connect the ground, positive, and negative wires as follows: •...
  • Page 40: Installing The Device

    Installing FastIron GS and FastIron GS-STK Devices Installing the device FIGURE 10 Connecting the wires to a DC power supply – Ground Power supply locking screw 10. Tug gently on each wire to make sure it is securely fastened in the connector. 11.
  • Page 41 Installing FastIron GS and FastIron GS-STK Devices Installing the device The Brocade device is compatible with two rack mount kits; a kit with short mounting brackets that ships with the device, and a kit with long mounting brackets (19 inches), which you can order separately from Brocade (part number 70166-000). Use the long mounting brackets to prevent the Brocade device from sagging when installed in a non-compliant (non-Telco) equipment rack.
  • Page 42 Installing FastIron GS and FastIron GS-STK Devices Installing the device FIGURE 12 Attaching the long mounting brackets Mount the device in the rack as illustrated in Figure NOTE Although Figure 13 shows a device with short mounting brackets, the procedure for securing a device with long mounting brackets is the same.
  • Page 43: Installing Fastiron Gs-Stk Stackable Devices

    Installing FastIron GS and FastIron GS-STK Devices Installing the device Installing FastIron GS-STK stackable devices Install your stackable devices in the same manner as standalone devices. When you have installed all of your stack devices in a rack or on a table, you will need to cable them together into a stack topology.
  • Page 44 Installing FastIron GS and FastIron GS-STK Devices Installing the device FIGURE 14 Linear stack topology Stack Lnk-Act Console Even 5 6 7 8 PS1 PS2 Pwr FGS-2XG Stack Lnk-Act Console Even 5 6 7 8 PS1 PS2 Pwr FGS-2XG Stack Lnk-Act Console Even...
  • Page 45: Powering On The System

    Installing FastIron GS and FastIron GS-STK Devices Powering on the system NOTE If you plan to upgrade your existing FGS devices to support stacking, you will need to install an upgrade kit. Refer to “Stacking Upgrade for the FastIron GS” on page 53.
  • Page 46: Powering Off The System

    Installing FastIron GS and FastIron GS-STK Devices Verifying proper operation If your device has more than one power supply installed, repeat this procedure for each power supply. Verify the device is working properly (refer to “Verifying proper operation” on page 46.) Powering off the system •...
  • Page 47 Installing FastIron GS and FastIron GS-STK Devices Attaching a PC or terminal You will need to assign an IP address using the CLI. You can access the CLI by attaching management station through a serial cable to the Console port. After you assign an IP address, you can access the system through Telnet, the Web management interface, or IronView Network Manager.
  • Page 48 Installing FastIron GS and FastIron GS-STK Devices Attaching a PC or terminal Most PC serial ports also require a cable with a female DB-9 connector. Terminal connections will vary, requiring either a DB-9 or DB-25 connector, male or female. Serial cable options between a Brocade switch or router and a PC or terminal are shown in Figure NOTE As indicated in...
  • Page 49: Eprem Upgrade For Fastiron Gs Devices

    EPREM Upgrade for FastIron GS Devices These installation instructions describe how to upgrade your standalone FastIron GS device to support Edge Layer 3 features (software release FGS 04.3.01 and later). If you have any questions about performing this upgrade, please contact your place of purchase or Brocade at 1.877.TURBOCALL (887.2622) inside the United States or 408.207.1600 outside the United States.
  • Page 50: Remove The Cover From The Device

    EPREM Upgrade for FastIron GS Devices Upgrading hardware Remove the cover from the device Remove any power cables from the device. TABLE 1 WARNING Disconnect the power cord from all power sources to completely remove power from the device. ACHTUNG Ziehen Sie das Stromkabel aus allen Stromquellen, um sicherzustellen, dass dem Gerät kein Strom zugeführt wird.
  • Page 51 EPREM Upgrade for FastIron GS Devices Upgrading hardware FIGURE 2 Removing the cover from an FGS device. Sl ot 3 Installing the EEPROM Remove the EEPROM from the package and align the lead pins over the EEPROM socket. Refer to Figure 3 on page 52 for the EEPROM socket location on FGS devices.
  • Page 52: Upgrading Software

    EPREM Upgrade for FastIron GS Devices Upgrading software FIGURE 3 EEPROM Socket Locations on FGS 624 and 648 Devices Device front panel Power supplies Device rear panel Pin 1 and socket hole 1 EEPROM socket EEPROM Memory DIMM Replace the cover: •...
  • Page 53: Stacking Upgrade For The Fastiron Gs

    Stacking Upgrade for the FastIron GS To upgrade your device, you will need to replace the current 128 MB memory with 256 MB memory, and install the stacking EEPROM. One upgrade kit also includes a CX4 module for units that do not already have this module installed. Refer to “Upgrade kit contents”...
  • Page 54: Upgrading Hardware

    Stacking Upgrade for the FastIron GS Upgrading hardware Upgrading hardware You need a Phillips-head screwdriver and an ESD wrist strap to perform this procedure. You also need a static-free work area. Table 0.3: WARNING Disconnect the power cord from all power sources to completely remove power from the device.
  • Page 55 Stacking Upgrade for the FastIron GS Upgrading hardware FIGURE 2 Removing the cover from FGS Devices Sl ot 3 Remove the EEPROM from the package and align the lead pins over the EEPROM socket. Refer to Figure 3 on page 56 for the EEPROM socket and Memory DIMM locations on FGS devices.
  • Page 56 Stacking Upgrade for the FastIron GS Upgrading hardware FIGURE 3 EEPROM and Memory DIMM Locations on FGS Devices To replace the memory DIMM, refer to Figure 5 on page 57. Open the DIMM holder by pushing the tabs apart. Lift the old DIMM up and pull it out of the holder.
  • Page 57 Stacking Upgrade for the FastIron GS Upgrading hardware FIGURE 4 FGS memory DIMM Slide the new DIMM into the holder at an angle (refer to the illustration) and push the connector end into the holder until it snaps into place. 10.
  • Page 58 Stacking Upgrade for the FastIron GS Upgrading hardware 11. If you are also installing a CX4 10GB module, proceed to step 12 step 13. If you are not installing a CX4 module, proceed step 12. Remove the cover plate from the module slot on the front panel, as shown in Figure FIGURE 6 Remove cover plate from 10 Gbps module slot...
  • Page 59: Upgrading Software

    Stacking Upgrade for the FastIron GS Upgrading Software 16. Reinstall the device in an equipment rack, if necessary. 17. Reconnect power cables to the device. Your memory and stacking EEPROM hardware upgrade is now complete. Proceed to the next section which has procedures for upgrading your software.
  • Page 60 Stacking Upgrade for the FastIron GS Upgrading Software Brocade FastIron GS and GS-STK Hardware Installation Guide Part Number: 53-1002186-03...
  • Page 61: Connecting Network Devices And Checking Connectivity

    Connecting Network Devices and Checking Connectivity Assigning permanent passwords The procedures in this manual are intended for qualified service personnel. Table 1 lists the tasks you must perform to connect your Brocade device, and shows you where to find troubleshooting information for any problems that may arise.
  • Page 62: Assigning A Password To An Ironstack

    Connecting Network Devices and Checking Connectivity Assigning permanent passwords • Read Only – Allows access to the Privileged EXEC mode and CONFIG mode but only with read access. To set passwords: At the opening CLI prompt, enter the following command to change to the Privileged level of the EXEC mode: FGS 624>...
  • Page 63: Configuring Ip Addresses

    Connecting Network Devices and Checking Connectivity Configuring IP addresses Configuring IP addresses You must configure at least one IP address using the serial connection to the CLI before you can manage the system using the other management interfaces. In addition, Brocade routers require an IP subnet address for the subnet in which you plan to place them in your network.
  • Page 64 Connecting Network Devices and Checking Connectivity Configuring IP addresses Syntax: [no] ip address <ip-addr> <ip-mask> [ospf-ignore | ospf-passive | secondary] Syntax: [no] ip address <ip-addr>/<mask-bits> [ ospf-ignore | ospf-passive | secondary] The ospf-ignore | ospf-passive parameters modify the switch defaults for adjacency formation and interface advertisement. Use one of these parameters if you are configuring multiple IP subnet addresses on the interface but you want to prevent OSPF from running on some of the subnets.
  • Page 65: Devices Running Layer 2 Software

    Connecting Network Devices and Checking Connectivity Configuring IP addresses This section describes how to configure an IP address on a virtual interface. NOTE The Brocade FGS device uses the lowest MAC address on the device (the MAC address of port 1 or 1/1) as the MAC address for all ports within all virtual interfaces you configure on the device.
  • Page 66: Devices Running Stacking Software

    Connecting Network Devices and Checking Connectivity Connecting network devices Access the configuration level of the CLI by entering the following command: FastIron Privileged EXEC Level # configure terminal FastIron Global CONFIG Level (config)# Configure the IP address and mask for the switch. FastIron(config)# ip address 192.22.3.44 255.255.255.0 Set a default gateway address for the switch.
  • Page 67: Connecting To Workstations, Servers, Or Routers

    Connecting Network Devices and Checking Connectivity Connecting network devices FIGURE 1 UTP Crossover Cable UTP Crossover Cable 10/100BaseTX Unused - - Unused Unused - - Unused Unused - - Unused - Unused Unused - FIGURE 2 Cat-5 Crossover Cable for 1000Base-T Cat-5 Crossover Cable 1000BaseT NOTE...
  • Page 68: Connecting A Network Device To A Fiber Port

    Connecting Network Devices and Checking Connectivity Connecting network devices For more information about this feature and how configure it, refer to the <Italic>FastIron Configuration Guide. Connecting a network device to a fiber port For direct attachment from the Brocade device to a Gigabit NIC, switch, or router, fiber cabling with an LC connector is required. To connect the Brocade device to another network device using a fiber port, you must do the following: •...
  • Page 69: Using A Cx4 Transceiver

    Connecting Network Devices and Checking Connectivity Testing connectivity To clean the fiber cable connectors, Brocade recommends using the fiber-optic cleaner that shipped with your Brocade device. You can also purchase this type of cleaner from the following Website: http://www.fisfiber.com When not using an SFP or XFP connector, make sure to keep the protective covering on. Using a CX4 transceiver FGS and FGS-STK devices support a twin-axial 10G copper CX4 XFP transceiver that can be installed in any 10G port.
  • Page 70: Pinging An Ip Address

    Connecting Network Devices and Checking Connectivity Testing connectivity Pinging an IP address To verify that a Brocade device can reach another device through the network, enter a command such as the following at any level of the CLI on the Brocade device: FastIron>...
  • Page 71: Tracing A Route

    Connecting Network Devices and Checking Connectivity Troubleshooting network connections Tracing a Route To determine the path through which a Brocade FGS or FGS-STK device can reach another device, enter a command such as the following at any level of the CLI on the Brocade device: FGS 624>...
  • Page 72: Digital Optical Monitoring

    Connecting Network Devices and Checking Connectivity Troubleshooting network connections Command syntax To diagnose a cable using TDR, enter a command such as the following at the Privileged EXEC level of the CLI: FGS 624# phy cable-diag tdr 1 This command diagnoses the cable attached to port 1. Syntax: phy cable-diag tdr <port-num>...
  • Page 73 Connecting Network Devices and Checking Connectivity Troubleshooting network connections You can configure your Foundry device to monitor optical transceivers in the system, either globally or by specified port. When this feature is enabled, the system monitors the temperature and signal power levels for the optical transceivers in the specified ports. Console messages and syslog messages are sent when optical operating conditions fall below or rise above the XFP or SFP manufacturer’s recommended thresholds.
  • Page 74 Connecting Network Devices and Checking Connectivity Troubleshooting network connections Brocade FastIron GS and GS-STK Hardware Installation Guide Part Number: 53-1002186-03...
  • Page 75: Hardware Specifications Device Specifications

    Hardware Specifications Device specifications Physical dimensions and weight Table 1 lists the physical dimensions and weight of FastIron GS and GS-STK devices and modules. TABLE 1 Physical Dimensions and Weight of FGS and FGS-STK Devices and Modules Platform Height Width Depth Weight •...
  • Page 76: Cooling

    Hardware Specifications Device specifications TABLE 2 Environmental Conditions for the Device (Continued) Description Range Operating altitude 6,600 feet maximum ° ° Relative humidity 5 to 95%, @ 104 F (40 C), non-condensing 5 to 95% non-condensing for DC power supply Operating noise 47 –...
  • Page 77: Regulatory Compliance

    Hardware Specifications Device specifications Regulatory compliance Table 3 lists the Electromagnetic Compatibility (EMC), Immunity standards, and safety agency approvals for FastIron GS and FastIron GS-STK switches. TABLE 3 Device Regulatory Compliance Description Certifications Electromagnetic Emissions FCC Part 15, Subpart B (Class A) EN 55022 (CE mark) (Class A) ICES-003 (Canada) (Class A) AS/NZ 55022 (Australia) (Class A)
  • Page 78: Mean Time Between Failure

    Hardware Specifications Device specifications Mean Time Between Failure Table 5 lists the Mean Time Between Failure (MTBF) for the FastIron GS, FastIron GS-STK, and 10 Gbps uplink modules. The MTBF is the average estimated time, in hours, before a hardware failure may occur. TABLE 5 MTBF for the FastIron GS and GS-STK and 10 Gbps Modules Configuration/Module...
  • Page 79: Pinouts And Signalling

    Hardware Specifications Device specifications Pinouts and signalling This section lists the pinouts for the DB-9 connector and RJ-45 port jacks. Serial (Console) port pinouts The Console port is a standard male DB-9 connector, as shown in Figure FIGURE 2 Serial port pin and signalling details Pin Assignment Pin Number Switch Signal...
  • Page 80: Cable Specifications

    Hardware Specifications Device specifications 10/100/1000 Gigabit port pinouts Table 4 lists the pin assignment and signalling for 10/100/1000 ports. FIGURE 4 Pin assignment and signalling for 10/100/1000 ports 10BaseT 100BaseTX and 1000BaseT Pin Assignment MDI-X ports Pin Number MDI-X ports Pin Number Not used Not used...
  • Page 81: Power Cords

    Hardware Specifications Device specifications TABLE 7 Cable Length Summary (Continued) Cable Type Connector Type Core Diameter Modal Bandwidth Range (meters) (microns) (MHz*km) or Wavelength (nm) 1000Base-SX LC connector for SFP 62.5/125 .5 – 275 module 62.5/125 .5 – 550 50/125 .5 –...
  • Page 82: Power Supply Specifications

    Hardware Specifications Power supply specifications Power supply specifications This section contains the following information for the power supplies that ship with FGS and FGS-STK devices. Overview Each FGS or FGS-STK switch comes with one alternating-current (AC) or direct-current (DC) power supply, depending on how it was ordered from the factory.
  • Page 83: Physical Dimensions And Weight

    Hardware Specifications Power supply specifications Physical dimensions and weight TABLE 8 Physical Dimensions and Weight of Power Supplies Power Supply Dimensions Weight RPS-FGS 6.25 cm (H) x 22.03 cm (W) x 19.30 cm (D) 3.016 kg (6.65 lbs) RPSDC-FGS 2.72 kg (6 lbs) 2.46 in (H) x 8.67 in (W) x 7.6 in (D) Environmental considerations For optimal performance, operate or store the power supplies in compliance with the following environmental conditions.
  • Page 84: Input Connector And Plug

    Hardware Specifications Power supply specifications TABLE 10 Maximum Power Supply Consumption for FGS Models (Continued) Model Maximum Power Consumption FGS624 power drawn from outlet with 1 power supply without uplink with 2 CX4+1XFP 99 W with 2XFP+1XFP 121 W with Combo+1XFP 121 W 121 W FGS648 power drawn from outlet with 1 power supply...
  • Page 85 Hardware Specifications Power supply specifications TABLE 12 Input Connector for Power Supplies Power Supply Input Connector Properties RPS-FGS Standard IEC type (IEC 320) C14 type: UL/CSA 15A/250V, VDE 10A/250V Orientation: Ground pin down RPSDC-FGS 2-position Phoenix Contact The power supply is connected to Earth Ground using wire attached to the ground stud on the power supply rear panel.
  • Page 86: Regulatory Compliance

    Hardware Specifications Power supply specifications FIGURE 6 DC power connector Negative terminal screw Positive terminal screw 48 RTN lead -48 VDC lead 10 AWG wire FIGURE 7 Connecting DC power supply – Ground Power supply locking screw Regulatory compliance The power supplies comply with the conducted and radiated test, immunity, and safety standards as listed in Table Brocade FastIron GS and GS-STK Hardware Installation Guide Part Number: 53-1002186-03...
  • Page 87: Safety Warnings

    Hardware Specifications Power supply specifications TABLE 13 Power Supply Regulatory Compliance Description Certifications Electromagnetic Emissions FCC Part 15, Subpart B (Class A) EN 55022 (CE mark) (Class A) ICES-003 (Canada) (Class A) AS/NZ 55022 (Australia) (Class A) VCCI (Japan) (Class A) EN 61000-3-2 EN 61000-3-3 KN 22...
  • Page 88 Hardware Specifications Power supply specifications TABLE 15 Power Supply Electrical Specifications Description Ranges Input Specifications Input voltage range 100 to 240 VAC -40 to -60 VDC Input current 8 Amps 18 Amps Inrush current < 11.25 Amps peak maximum < 26 Amps peak maximum Output Specifications Output power 600 watts of total output power, including +12VDC @ 10A to the system...
  • Page 89: Managing The Fgs And Fgs-Stk Device

    Managing the FGS and FGS-STK Device Managing temperature settings This section describes how to display temperature settings on the FGS or FGS-STK device, and how to change the temperature warning levels. Using the temperature sensor FGS and FGS-STK devices come with two built-in temperature sensors; one at the air intake to monitor the incoming air temperature, and the other at the exhaust, to measure the air temperature as it exits the device.
  • Page 90: Displaying Temperature Messages

    Managing the FGS and FGS-STK Device Managing temperature settings FGS648P Switch#show chassis The stack unit 1 chassis info: Power supply 1 (NA - AC - Regular) present, status ok Power supply 2 not present Fan 1 ok Fan 2 ok Exhaust Side Temperature Readings: Current temperature : 35.5 deg-C Warning level..: 80.0 deg-C...
  • Page 91: Changing The Device Temperature Polling Interval

    Managing the FGS and FGS-STK Device Removing MAC address entries To change the temperature at which the device sends a warning, enter a command such as the following at the Privileged EXEC level of the CLI: FastIron# temperature warning 47 Syntax: temperature warning <value>...
  • Page 92 Managing the FGS and FGS-STK Device Removing MAC address entries • A specified MAC address entry in all VLANs For example, to remove entries for the MAC address 000d.cb80.00d in all VLANs, enter the following command at the Privileged EXEC level of the CLI: FastIron# clear mac-address 000d.cb80.00d0 Syntax: clear mac-address <mac-address>...
  • Page 93: Maintaining The Fgs And Fgs-Stk Hardware

    Maintaining the FGS and FGS-STK Hardware Hardware maintenance schedule TThe procedures in this manual are for qualified service personnel. The FGS and FGS-STK hardware components require minimal maintenance. Brocade recommends cleaning the fiber optic connectors on fiber optic ports and the connected fiber cable each time you disconnect the cable. You can replace the following hardware components as needed: •...
  • Page 94: Installation Precautions And Warnings

    Maintaining the FGS and FGS-STK Hardware Replacing a power supply Installation precautions and warnings Follow these precautions when installing a power supply in the FGS and FGS-STK device. Before beginning the installation, refer to the precautions in “Power precautions” on page 31. Do not install the device in an environment where the operating ambient temperature might exceed 40 Deg.
  • Page 95: Installing Or Replacing A 2-Port 10 Gbps Module

    Maintaining the FGS and FGS-STK Hardware Replacing a power supply Installing or replacing a 2-port 10 Gbps module The 2-port 10-Gigabit Ethernet module is optional. You can order the FGS or FGS-STK with a 2-port 10-Gigabit module installed at the factory, or you can upgrade your device later.
  • Page 96: Installing A 2-Port 10 Gbps Module

    Maintaining the FGS and FGS-STK Hardware Installing or replacing a POE daughter card Installing a 2-port 10 Gbps module Follow these procedures and refer to Figure 2 when installing a 10-Gigabit Ethernet Module: Remove power to the FGS or FGS-STK device. For AC power supplies, turn the switch to the OFF position. For DC power supplies, turn off the DC power source or disconnect it from the power supply.
  • Page 97: Disassembling The Device

    Maintaining the FGS and FGS-STK Hardware Installing or replacing a POE daughter card To install or replace a POE daughter card, you must have the following on hand: • A POE daughter card (part number FGS-24GCPOE), which you can order from Brocade. •...
  • Page 98: Installing A Poe Daughter Card

    Maintaining the FGS and FGS-STK Hardware Installing or replacing a POE daughter card FIGURE 4 Removing the Cover FG S- 2X Proceed to “Installing a POE daughter card”. Installing a POE daughter card To replace or install the POE daughter card, do the following: Disassemble the device as instructed in the section “Disassembling the device”...
  • Page 99: Reassembling The Device

    Maintaining the FGS and FGS-STK Hardware Installing or replacing a POE daughter card FIGURE 6 Installing a POE Daughter Card in the FGS624P-POE or FGS624P-POE-STK device Figure 7 shows the location of the POE daughter cards on the main board of the FGS648P-POE and FGS648P-POE-STK devices.
  • Page 100: Replacing A Fiber Optic Module

    Maintaining the FGS and FGS-STK Hardware Replacing a fiber optic module If the device is rack-mounted, replace the mounting brackets. Replacing a fiber optic module You can remove an SFP or XFP module from a port and replace it with a new one while the FGS is powered on and running. This section describes the following tasks: •...
  • Page 101: Installing A New Fiber Optic Module

    Maintaining the FGS and FGS-STK Hardware Cleaning the fiber optic connectors Store the copper or fiber optic module in a safe, static-free place or in an anti-static bag. Install a new copper or fiber optic module in the port. For information about performing this task, refer to “Installing a new fiber optic module”.
  • Page 102 Maintaining the FGS and FGS-STK Hardware Cleaning the fiber optic connectors To clean the fiber cable connectors, Brocade recommends using the fiber-optic reel-type cleaner that shipped with your Brocade device. You can also purchase this type of cleaner from the following Website: http://www.fisfiber.com When not using an SFP or XFP connector, make sure to keep the protective covering on.
  • Page 103: Regulatory Statements

    Regulatory Statements U.S.A. This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 104: Japan Power Cord

    Regulatory Statements Japan power cord Japan power cord English translation of above statement ATTENTION: Never use the power cord packed with your equipment for other products. Korea A 급 기기 ( 업무용 방송통신기기 ): 이 기기는 업무용 (A 급 ) 으로 전자파적합등록 을...
  • Page 105 Regulatory Statements Russia -3177 15.09.2009 15.09.2014 25.09.2009 English translation of above statements Verification of conformity by Mincomsvyaz (Ministry of communication) of Russia: Declaration of conformity No. D-SPD-XXXX of DD.MM.YYYY, valid till DD.MM.YYYY, registered in Federal Communication Agency on DD.MM.YYYY Brocade FastIron GS and GS-STK Hardware Installation Guide Part Number: 53-1002186-03...
  • Page 106: China

    Regulatory Statements China China China-CCC Warning statements 在维修的时候一定要断开所有电源 (English translation“disconnect all power sources before service”) For non tropical use: 汉文  “仅适用于非热带气候条件下安全使用。”  藏文  安全 蒙古 说明 文 和标 Dan hab yungh youq gij dienheiq diuzgen mbouj dwg diegndat 壮文  记  haenx ancienz sawjyungh. 维文 ...
  • Page 107: Cautions And Warnings

    Cautions and Warnings The cautions and warnings that appear in this manual are listed below in English, German, French, and Spanish. Cautions A caution calls your attention to a possible hazard that can damage equipment. “Vorsicht” weist auf die Gefahr einer möglichen Beschädigung des Gerätes in. Une mise en garde attire votre attention sur un risque possible d'endommagement de l'équipement.
  • Page 108 Cautions and Warnings Cautions Table 0.2: CAUTION Remove the power cord from a power supply before you install it in or remove it from the device. Otherwise, the power supply or the device could be damaged as a result. (The device can be running while a power supply is being installed or removed, but the power supply itself should not be connected to a power source.) VORSICHT...
  • Page 109 Cautions and Warnings Cautions Table 0.5: CAUTION Use a separate branch circuit for each AC power cord, which provides redundancy in case one of the circuits fails. VORSICHT Es empfiehlt sich die Installation eines separaten Stromkreiszweiges für jede Wechselstrom-Elektroschnur als Redundanz im Fall des Ausfalls eines Stromkreises. MISE EN GARDE Utilisez un circuit de dérivation différent pour chaque cordon d’alimentation C.A.
  • Page 110 Cautions and Warnings Cautions Table 0.7: CAUTION All devices with DC power supplies are intended for installation in restricted access areas only. A restricted access area is where access can be gained only by service personnel through the use of a special tool, lock and key, or other means of security, and is controlled by the authority responsible for the location.
  • Page 111 Cautions and Warnings Cautions Table 0.9: CAUTION For the DC input circuit to the system (DC power supply part number RPSDC-FGS), make sure there is a 30 amp circuit breaker, minimum -48Vdc, double pole, on the input to the terminal block. The input wiring for connection to the product should be copper wire, 10 AWG, marked VW-1, and rated minimum 90 degrees celcius.
  • Page 112 Cautions and Warnings Cautions Table 0.11: CAUTION Use the erase startup-config command only for new systems. If you enter this command on a system you have already configured, the command erases the configuration. If you accidentally do erase the configuration on a configured system, enter the write memory command to save the running configuration to the startup-config file.
  • Page 113 Cautions and Warnings Cautions Table 0.14: CAUTION Remove the power cord from a power supply before you install it in or remove it from the device. Otherwise, the power supply or the device could be damaged as a result. (The device can be running while a power supply is being installed or removed, but the power supply itself should not be connected to a power source.) VORSICHT...
  • Page 114 Cautions and Warnings Warnings Table 0.16: CAUTION Do not push too hard. If the EEPROM does not readily go into the socket, stop pushing and verify that the lead pins are straight and aligned over the holes. Straighten any crooked pins, then try again.
  • Page 115 Cautions and Warnings Warnings Un avertissement attire votre attention sur un risque possible de blessure ou de décès. Ci-dessous, vous trouverez les avertissements utilisés dans ce manuel. Una advertencia le llama la atención sobre cualquier posible peligro que pueda ocasionar daños personales o la muerte. A continuación se dan las advertencias utilizadas en este manual.
  • Page 116 Cautions and Warnings Warnings Table 0.23: WARNING Disconnect the power cord from all power sources to completely remove power from the device. ACHTUNG Ziehen Sie das Stromkabel aus allen Stromquellen, um sicherzustellen, dass dem Gerät kein Strom zugeführt wird. AVERTISSEMENT Débranchez le cordon d'alimentation de toutes les sources d'alimentation pour couper complètement l'alimentation du dispositif.
  • Page 117 Cautions and Warnings Warnings Table 0.26: WARNING If the installation requires a different power cord than the one supplied with the device, make sure you use a power cord displaying the mark of the safety agency that defines the regulations for power cords in your country. The mark is your assurance that the power cord can be used safely with the device.
  • Page 118 Cautions and Warnings Warnings Table 0.28: WARNING Before beginning the installation, refer to the precautions in “Power precautions” page 31. ACHTUNG Vor der Installation siehe Vorsichtsmaßnahmen unter“Power precautions” (Vorsichtsmaßnahmen in Bezug auf elektrische Ablagen) auf den Seiten 4. AVERTISSEMENT Avant de commencer l'installation, consultez les précautions décrites dans “Power precautions”...

Table of Contents
