Rear View Mirror Cushion Attachment
2
3
1. Tape affix mark rib
2. Tape
: Tape should not run over the indicated line.
3. Boss
: Bosses should contact to the cushion when assembled.
4
1
" a "
4. Cushion
: Align the cushion corner to the indicated point.
"a": 1.5 mm (0.06 in)
Exterior Parts:
9D-9
B837H19406022
4
I837H1940034-03
