Silicon Graphics Altix XE250 User Manual page 65

007-5467-001
Load lever
9. If the CPU is properly installed into the socket, the PnP cap is automatically released from
the load plate when the lever locks.
Caution: Retain the plastic PnP cap for shipping. The node board must be shipped with
!
the PnP cap properly installed to protect the CPU socket. Shipment without the PnP cap
properly installed may void the warranty.
10. Remove the PnP cap.
Processor and Heatsink Installation and Removal
3-37
