3: Advanced Node Board Setup
Power On LED Pin Definitions (JF1)
NMI Switch Pin Definitions (JF1)
Fan Connector Pin Definitions (Fan1/2 - Fan7/8)
3-64
Table 3-15
Power On LED Pin Definitions (JF1)
The Power On LED connector is located on pins 15 and 16 of JF1
(refer to
Figure 3-15 on page
indicate that power is supplied to the system.
Table 3-16
NMI Button Pin Definitions (JF1)
The non-maskable interrupt button connector is located on pins 19
and 20 of JF1 (refer to
Figure 3-15 on page
Table 3-17
lists the Altix XE250 fan connector pin definitions.
connector locations on the node board.
Notes
61). Use this connection is used to
Notes
61).
Power On LED Pin Definitions
JF1
Pin#
Definition
15
5V Standby
16
Control
Power On LED Pin Definitions
JF1
Pin#
Definition
19
Vcc
20
Ground
Figure 3-16
shows the fan
007-5467-001
