NIC2 LED Pin Definitions (JF1)

NIC1 LED Pin Definitions (JF1)

HDD LED Pin Definitions (JF1)

007-5467-001
Table 3-12

NIC2 LED Pin Definitions (JF1)

The NIC2 LED connection (LAN2) is on pins 9 and 10 of JF1
(refer to Figure 3-15 on page
LAN 2.
Table 3-13

NIC1 LED Pin Definitions (JF1)

The NIC1 LED connection is on pins 11 and 12 of JF1 (refer to
Figure 3-15 on page 61) and displays network activity on LAN 1.
Table 3-14

HDD LED Pin Definitions (JF1)

The HDD LED connection is located on pins 13 and 14 of JF1
(refer to Figure 3-15 on page
cable here to display disk activity (for any disk drives in the
system, including SAS, serial ATA and IDE disk drives).
Notes
61) and displays network activity on
Notes
Notes
61). Attach the hard drive LED
Node Board Connector Pin Definitions
NIC2 LED Pin Definitions
JF1
Pin# Definition
9 Vcc
10 Ground
NIC1 LED Pin Definitions
JF1
Pin# Definition
11 Vcc
12 Ground
HDD LED Pin Definitions
JF1
Pin# Definition
13 Vcc
14 HD Active
3-63
