Secondary Power Connector Pin Definitions (JPW2)

Secondary Power Connector Pin Definitions (JPW3)

3-60
Table 3-6

Secondary Power Connector Pin Definitions (JPW2)

Notes
A 4-pin 12V auxiliary power connector is included to
provide power to hard drive disks.
Table 3-7

Secondary Power Connector Pin Definitions (JPW3)

Notes
A 4-pin 12V auxiliary power connector is included to
provide power to hard drive disks.
Secondary Power Pin Definitions
JPW2
Pin# Definition
1 +12V
2 Ground
3 Ground
4 +5V
Secondary Power Pin Definitions
JPW3
Pin# Definition
1 +12V
2 Ground
3 Ground
4 +5V
