B: IPMI 2.0 Management Utility
B-184
• Color Depth: Click on the arrow on the right to select either 16 bit-high colors or 8 bit-256
colors. The standard color depth is 16 bit-high color. This setting is recommended for
compression level 0. For typical desktop interfaces, the setting of 8 bit-256 colors is
recommended for faster data transmission.
• Remote Console Type: This field enables you to decide which Remote Console Viewer to
use.
• Default Java VM (JVM): Select this option to use the default Java Virtual Machine (JVM)
of your web browser. This can be the Microsoft JVM for Internet Explorer or the Sun JVM
depending on the configuration of your browser.
• Sun Microsystems Java Browser Plugin: Select this option when the JVM used to run the
code for the Remote Console is a Java applet. If you use this function for the first time and
the appropriate Java plugin is not yet installed in your system, you may download and install
it automatically. To download and install it, you need to check "yes" in the dialogs.
Note: If your internet connection is slow, please pre-install the JVM on your administration
machine.
• Miscellaneous Remote Console Settings: This window enables you to specify the
following Remote Console Settings.
• Start in Monitor Mode: Check this box to enable the Start in Monitor Mode which enable
data to be displayed in the remote monitor as soon as Remote Console is activated. (The data
displayed in the remote monitor is read-only.)
• Start in Exclusive Access Mode: Check this box to enable the exclusive access mode
immediately at Remote Console startup which forces all other users connected to the
network to close their connection. No other users can open the Remote Console until you
disable this function or log off.
• Mouse Hotkey: This option enables you to use a hotkey combination to specify the mouse
synchronization mode or the single mouse mode.
• Hotkey: Enter a hotkey combination in the box to specify the mouse synchronization mode
or the single mouse mode.
• Remote Console Button Keys: This window enables you to define button keys for the
remote host. The button keys allow simulating keystrokes on a remote host or issuing
commands to a remote system. The button keys are needed when you have a missing key or
when you want to prevent interference caused to the local system. After a remote console
button key is set, it displays on the right upper corner of the remote monitor screen.
• Button Keys: Enter the syntax of a button enter the box.
