2: Server Installation

Install the Chassis Rails

2-20
Note: The chassis rail may be factory installed on the system. Perform the following procedure to
install the chassis rails only if necessary (refer to
5. Position the rack rails on the chassis as shown in
on the chassis.
6. Install two screws to secure the rail to the chassis. (Refer to
Both chassis rails have a locking tab (refer to
to lock the server into place when it is installed in the rack; the second is to lock the server in place
when it is fully extended from the rack. The locking tab prevents the server from being removed
from the rack accidentally when you pull it out for service.
2
1
Figure 2-2
Chassis Rail Installation
Figure 2-2).
Figure 2-2 and slide the rail under the tabs
Figure
Figure 2-2), which serves two functions: the first is
2-2.)
Locking tab
