Table B-1 Health Monitoring Sensors - Silicon Graphics Altix XE250 User Manual

B: IPMI 2.0 Management Utility
Temperature Monitoring
Voltage Monitoring
Fan Control
Physical Security
Node Board CPU0 Internal Err
Node Board CPU1 Internal Err
Node Board CPU Overheat
Node Board Thermal Trip
B-176
Table B-1
Health Monitoring Sensors
CPU1 Temperature (Temp A, Temp B)
CPU2 Temperature (Temp A, Temp B)
System Temperature
CPU1 VCore
CPU2 VCore
3.3V
5V, 5VSB
+12V, -12V
1.5V
VBAT
Fan1/CPU Fan
Fan2/CPU Fan
Fan 3 – Fan 6
Chassis Intrusion
Temp A: CPU1 Core1 Temperature
Temp B: CPU1 Core2 Temperature
Temp A: CPU2 Core1 Temperature
Temp B: CPU2 Core2 Temperature
CPU1 Vcore: CPU1 Core Voltage
CPU2 Vcore: CPU2 Core Voltage
5VSB: 5V Standby
VBAT: Battery voltage
When the CPU temperature exceeds this preset
temperature, the overheat LED or alert is triggered,
the CPUs slow down, the CPU fans are in the full
speed mode.
When the system temperature exceeds this preset
temperature, the overheat LED or alert is triggered,
and the cooling fans are in the full speed mode to
prevent system overheat.
007-5467-001
