Wake on Ring Connector Pin Definitions (JWOR)

Chassis Intrusion Connector Pin Definitions (JL1)

007-5467-001
Table 3-20

Wake on Ring Connector Pin Definitions

The Wake-On-Ring connector (JWOR) connector
Figure 3-26)
enables the system to receive and be "awakened" by an
incoming call when in the suspend state. You must also have the
WOR card and cable installed to use this feature.
Table 3-21 lists the chassis intrusion connector pin definitions (JL1).
location of the connector JL1on the node board.
Figure 3-17
Chassis Intrusion Connector Location
Table 3-21 Chassis Intrusion Pin Definitions (JL1)
The chassis intrusion connector is designated JL1 (refer to
Figure 3-17). A cable connected to a chassis switch alerts you of
a chassis intrusion when the chassis is opened.
Notes
(refer to
JL1
COM2
JWOL SMB
Notes
Node Board Connector Pin Definitions
Wake-On-Ring Pin Definitions
JWOR
Pin# Definition
1 Ground (Black)
2 Wake-up
Figure 3-17shows the
JK1
Chassis Intrusion Pin Definitions
JL1
Pin# Definition
1 Intrusion Input
2 Ground
3-67
