3: Advanced Node Board Setup

Install a Heatsink

3-40
1. Ensure that you have replaced the thermal interface material (TIM) between the heatsink and
the CPU die.
Refer to section "Replace the Thermal Interface Material" on page
Caution: Use caution when you unpack the heat sink so you do not damage the TIM.
!
2. Place the heatsink on top of the CPU so that the four mounting holes are aligned with those
on the (preinstalled) heatsink retention mechanism.
Caution: Do not tighten the screws in step
!
3. Install two screws (screw #1 and screw #2, shown in
Caution: Do not overtighten tighten the screws in step
!
4. Install the two remaining screws (screw #3 and screw #4, shown in
tighten all four screws.
Heatsink
screws
Figure 3-7
Install a CPU Heatsink
3
#1
#3
#4
#2
41.
or you may damage the CPU.
Figure 3-7) and tighten until just snug.
4 or you may damage the CPU.
Figure 3-7); then, gently
