Node Board LED Descriptions

LAN1 and LAN2 (Ethernet Ports)

Onboard Power LED (LE1)

007-5467-001
Table 3-42 LAN1 and LAN 2 LED Descriptions
Notes
The Ethernet ports (located beside the serial COM2 port)
have two LEDs. On each Gigabit LAN port, one LED
indicates activity when blinking while the other LED may
be green, amber, or off to indicate the speed of the
connection.
Table 3-43 Onboard Power LED Description (LE1)
Notes
The Onboard Power LED (LE1) illuminates
when the system is on. Be sure to unplug the
power cable before removing or adding any
components.
Node Board LED Descriptions
LAN LED Speed Indicators
LAN1/LAN2
LED Color
Off 10 MHz
Green 100 MHz
Amber 1 GHz
Power LED
LE1
LED Color
Green (solid) Power is on and system is on
Green, flashing ACPI S1 State
quickly
Green, flashing ACPI S3 (STR) State
slowly
Off Power off or power cable not
connected
Description
Description
3-85
