3: Advanced Node Board Setup

Node Board Jumpers and Connectors

3-56
Refer to Figure 3-12 when using
Table 3-2 Node Board Default Jumper Settings
Jumper
JB3
JBT1
JCF1
JI 2 C1/JI 2 C2
JP1
JP2
JPL1
JWD
Table 3-3 Node Board Connector Descriptions
Connector
COM1/COM2
FAN 1-8
Floppy
IDE1/IDE2
I-SATA0 ~ I-SATA5
J3P
JAR
JD1
Table 3-2, Table 3-3 and
Description
3rd Power Fail Detect
CMOS Clear
Compact Flash Card
Master/Slave
I 2 C to PCIe Slot
Reboot option
Memory Voltage Select
LAN1/LAN2 Enable/Disable
Watch Dog
COM1/COM2 Serial Port Connector
Chassis/CPU Fan Connectors
Floppy Disk Drive Connector
IDE Drive/Compact Flash Card Connector
SATA Ports
PWR Supply Fail LED
Alarm Rest Connector
Onboard Speaker/Power LED
Table 3-4.
Default Setting
Open (Disabled)
Refer to "CMOS Memory Clear
(JBT1)" on page 77.
Closed (Master)
Open (Disabled)
Open (Reboot)
Pins 1-2 (Auto)
Pins 1-2 (Enabled)
Pins 1-2 (Reset)
Description
007-5467-001
