Setting communications without using DOCOMO
Connection Manager
The method of dialup connection setup without DOCOMO Connection Manager is explained.
I When using an access point compatible with HIGH-SPEED such as mopera for packet communication,
make settings using DOCOMO Connection Manager.
Flow of dialup network setting
Flow of setup for data communication
When the access point is mopera U or mopera, you do not need to set.
Operating system
Dialup connection
TCP/IP settings
* Set for packet communication.
Communication software to input AT commands is required for settings.
The method of setting using "
is explained here. Windows Vista does not support "
using the software supported by Windows Vista (Follow the method for the software to be used.).
Setting the dialup connection (APN)
The dialup connection (APN) and registration number (cid)
The dialup connections (APN) for packet communication can be set for registration numbers (cid) between
1 and 10 in FOMA terminal. "mopera.ne.jp" (APN) to connect to mopera is registered in cid1 and
"mopera.net" (APN) to connect to mopera U is registered in cid3 by default. For connecting to other
providers or corporate LANs, register APN for cid2 or 4-10.
I For the dialup connections (APN), inquire your provider or network administrator.
I For USB cable connection and Bluetooth connection, setting each dialup connections (APN) is required.
I For packet communication, if switching between USB cable connection and Bluetooth connection,
setting the dialup connections (APN) is required again.
I The dialup connection settings can be considered as phonebook entries registered for packet
communication. The comparison between dialup connection settings and FOMA terminal phonebook is
as shown below.
Dialup connection settings
Registration number (cid)
APN
I The registered cid become the connection number in the dialup connection numbers setting.
P4
Setting the dialup connection (APN)
Setting Show/Hide caller ID
Set as required.
Setting Dialup Network
Windows Vista
P22
P24
(HyperTerminal)" that comes with Windows 2000 and Windows XP
FOMA terminal phonebook entries
Registration number (Phonebook No.)
Party's phone number
18
*
P18
*
P20
Windows XP Windows 2000
P25
P27
(HyperTerminal)". For Windows Vista, set
P29
P32
