Docomo F-01A Instruction Manual page 506

List of AT command
I AT command that can be used via the FOMA F01A (Modem).
I Entering " " may cause "\" to appear depending on the font setting for a PC or communication software.
I If the battery pack is removed from FOMA terminal before the terminal power is turned off, the setting
values may not be recorded.
Upper slot : Command
Lower slot : Example
A/
A/
OK
AT
AT
OK
ATA
RING
ATA
CONNECT
ATD
ATD 99 1#
CONNECT 460800
ATE<n>
ATE1
OK
ATH
ATH
NO CARRIER
ATI<n>
ATI0
NTT DoCoMo
OK
ATO
ATO
CONNECT 460800
ATQ<n>
ATQ0
OK
ATS0=<n>
ATS0=0
OK
ATS2=<n>
ATS2=43
OK
ATS3=<n>
ATS3=13
OK
Execute the previously executed command again.
When previous response is "ERROR", "ERROR" is returned.
Use commands on this list by prefixing to commands other than A/ or +++. When using only
this command, "OK" is returned with FOMA terminal enabled for using AT commands.
Perform the receiving process when entered while receiving a packet communication or
64K data communication.
The following commands can be entered when receiving a packet communication.
ATA184 : Handling of incoming calls : Send caller ID function OFF
ATA186 : Handling of incoming calls : Send caller ID function ON
ATD 99 <cid># : Performs calling process for packet communication.
If <cid> or <cid> is omitted, <cid>=1 is set.
ATD [parameter] [phone number] : Perform calling process for 64K data communication.
Calling process is not permitted if phone number contains characters other than the
following.
0-9, , #, A, a, B, b, C, c
The following characters and a space can be entered but are not recognized in dialing.
,(comma), !, -, , D, d, P, p, T, t, W, w
Setting Show/Hide caller ID is enabled by inserting 186 or 184 after ATD.
ATDN or ATDL can be used for redial calling.
*1
Set whether FOMA terminal will return echo for command sent from a PC.
n=0 : Echo OFF n=1 : Echo ON (default)
Normal usage is n=1. If the PC has an echo function, setting this command to n=0 prevents
double display of characters.
Disconnect line when entered during a communication.
Execute in online command mode.
Display the confirmation code.
n=0 : "NTT DoCoMo"
n=2 : Display version of FOMA terminal
n=4 : Display details of functions that can be communicated by FOMA terminal in numeric
Return from online command mode to online data mode during communication.
*1
Set whether to display result code.
n=0 : Display (default)
When ATQ1 is executed, "OK" is not returned.
*1
Set number of rings until FOMA terminal receives communication automatically.
n=0 : Not receive automatically (default)
n=1-255 : Receive automatically with specified number of rings
ATS0? : Display current settings
Set escape character.
n=0-127 (default : n=43)
ATS2? : Display current settings
Set the carriage return (CR) character that identifies the end of AT command character
string. Appended to end of echoed command character string and result code.
n=13 (fixed value)
ATS3? : Display current settings
Description
P36
n=1 : Display model name of FOMA terminal
n=3 : Display elements of ACMP signals
n=1 : Not display
When n=127 is set, escape is unavailable.
37
