Setting Operations For Data Exchange; Data Exchange Settings; Displaying Pdf Data; My Document - Docomo F-01A Instruction Manual

Data exchange settings

Setting operations for data exchange

Operations for data exchange via infrared communication, iC transmission or
packet communication or 64K data communication or data transfer by connecting
with a PC can be set.
m [LifeKit] 25eSet required itemseC
1
End alert : Set whether to sound the end tone at the end of communications.
Auto authentication : Set whether to automatically exchange authentication
codes with the other party for packet communication, 64K data
communication or data transfer by connecting a PC.
To set to "ON", perform authentication and enter 4-8 digit Auth code: terminal
(FOMA terminal) and Auth code: PC (the other party) and press C.
Ph.book image sending : Set whether to send images saved in phonebook with
all phonebook entries.

Displaying PDF data

My Document

Displaying PDF data
You can operate from flip style. P40
m [Data Box] 6
1
The folder contents are as given below.
i-mode : PDF data acquired from a site or mail
Preinstalled : PDF data stored by default
Data transfer : PDF data acquired from microSD card or external device
My folder : PDF data moved from other folders
Appears if a folder is added. P308
When secret attribute is set,
2
Select a folder
a
Thumbnail display
a Originated
: Preinstalled : i-mode, Full Browser, mail
316
Data Management
is displayed.
b
I
c
a
List display
: Data transfer (including data attached to mail acquired by data transfer)
b File type
/ : PDF data/Unavailable due to UIM operation restriction
: PDF data partially saved
: PDF data failed in downloading
c File restriction
/ : File restricted/unrestricted
For thumbnail display, the display name of the file at the cursor position
appears at the top of the display, and the file size appears at the bottom of the
display. And, when thumbnail display is unavailable, the icons below are
displayed.
: PDF data not displayed after downloading or unable to acquire thumbnail
images
: PDF data partially saved and the thumbnail cannot be displayed
: PDF data failed in downloading
: Unavailable due to UIM operation restriction
Switching to microSD card list :
3
Select PDF data
When PDF data with password set is selected, a password entry screen
appears. Enter a password and press C.
When a PDF data failed in downloading is selected, a confirmation screen for
downloading remaining data appears.
At the bottom of the display, the current page number/total number of pages
and magnification are displayed.
Attaching to mail :
❖
Operation while displaying PDF data
k (Continuous scroll while pressing down)
Scrolling :
Displaying key function help :
Key operation is available while help is being displayed. Press g to return to the
original screen.
When full-screen display is set by pressing *, press * to restore the
b
original display.
c
An image cut out by pressing 9 is saved in "Camera" folder of My Picture in
JPEG format. An image may not be cut out for some security settings of PDF data.
The image size of cut out image is the same as the image area in PDF data. PDF
data setting is applied when attached to mail or output from FOMA terminal.
I
Move the cursor to PDF dataea
C
