2
Insert the other end of the USB cable connector into the PC USB port.
If you connect FOMA terminal to a PC before installing FOMA communication configuration file,
Windows may automatically detect that USB cable has been inserted and request the driver. In
such a case, remove FOMA terminal and click "
end.
When a PC and FOMA terminal are connected,
terminal.
Removing USB cable
1
Press the USB cable's release buttons on both sides of the connector ( a ) and
remove the connector from FOMA terminal ( b ).
2
Remove the USB cable out from the PC.
INFORMATION
Be careful not to give excessive force to the connecter of the USB cable when connecting/disconnecting the cable
to/from FOMA terminal. When disconnecting the connector, be sure to pull it straight while pressing the release
button. Applying an excessive force to disconnect the connector may give damage to it.
Do not remove the USB cable during data communication. The data communication is disconnected and it may
cause data loss or malfunction.
Make sure that the front
side shown with a seal,
, etc.
Connector
appears on the stand-by display of FOMA
Release button
a
b
Connector
6
(Cancel)" on the displayed screen to
Open the jack cap.
