Using Motion Sensor - Docomo F-01A Instruction Manual

Operations of pointing device and those of multi-cursor key are supported as
below.
Pointing device Multi-cursor key Side key on the sub-display menu
k
Slide
(Only right or left sliding is
available for side key
operations)
Continue touching after sliding k (1 sec. or more)
g
Double-tap
*
g (1 sec. or more)
Touch for 1 sec. or more
* Available only for Full Browser
When operating pointing device, do it with light touching. Scratching or giving
excessive force may damage the fingerprint sensor.
Setting the effective area or speed of pointing device
<Pointing device>
m [Settings & NW services] 77eSet required itemseC
1
Use sensor for: : Set the effective area for pointing device.
When setting to "F-browser/i-αppli", pointing device can be used only for Full
Browser and i-αppli.
If setting to "Not use", fingerprint sensor is available only for fingerprint
authentication.
Pointer speed : Set the moving speed for sliding operation.
Double-tap speed : Set the speed for double-tapping.
SD
P

Using motion sensor

Motion sensor allows you to perform various operations by double-tapping or
tilting FOMA terminal.
Stopping alarm sound by double-tapping FOMA terminal
If double-tapping (tapping twice) while alarm clock, schedule reminder or
countdown timer is sounding when FOMA terminal is folded, the sound stops.
Alarm clock stops or performs snooze operation.
Flash graphics change
When setting Flash graphics compatible with motion sensor to stand-by display,
image changes by moving FOMA terminal.
Changing orientation automatically when displaying an image
When displaying an image (JPEG format) in My Picture in flip style, vertical/
horizontal position or display size of the image automatically changes according to
the orientation of FOMA terminal.
Reversing the display on sub-display
When displaying sub-display with FOMA terminal folded, the orientation of FOMA
terminal is detected and the display changes accordingly.
Top
Bottom
Before Using the Handset
45
