3 Soft Counters

The machine is equipped with soft counters that count the number of prints it has
handled; the counter readings may be checked by pressing the Check key in the control
panel.
The counters are controlled by the main controller PCB, and each count is incremented
when any of the following sensors detects paper during copy/print operation:
When No Delivery Option Is Installed
Copy/print operation
Single-sided
Double-sided 1st side
2nd side
When the Inner 2-Way Tray Is Used
Copy/print operation
Single-sided
Double-sided 1st side
2nd side
2nd side
When a Finisher Is Installed
Copy/print operation
Single-sided
Double-sided 1st side
2nd side
When Delivery Is to the Saddle finisher
Copy/print operation
Single-sided
Double-sided 1st side
2nd side
COPYRIGHT © 2001 CANON INC.
Sensor used
PS15 No. 1 delivery sensor
PS18 Duplexing unit outlet sensor
PS15 No. 1 delivery sensor
Sensor used
PS19S No. 2 delivery sensor
PS21S No. 3 delivery sensor
PS18 Duplexing unit outlet sensor
PS19S No. 2 delivery sensor
PS21S No. 3 delivery sensor
PS21S No. 3 delivery sensor
Sensor used
S2 Inlet sensor
PS18 Double-sided outlet sensor
S2 Inlet sensor
Sensor used
PI1 Inlet sensor
PS18 Double-sided outlet sensor
PI1 Inlet sensor
T02-301-01
2000 2000 2000 2000 CANON iR2200/iR2800/iR3300 REV.0 MAR. 2001
CHAPTER 2 MAIN CONTROLLER
Delivery slot
Below the inside tray
Below the inside tray
Delivery slot
Above the inside tray
Outside tray
Above the inside tray
Above the inside tray
Outside tray
Delivery slot
Finisher delivery tray
Finisher delivery tray
Delivery slot
Finisher delivery tray
Finisher delivery tray
