<DC-CON (5/7)>
Address bit Notation
P018 0
1
2
3
4
5
6
7
P019 0
1
2
3
4
5
6
7
P020 0
1
2
3
4
5
6 M9
7 M9
P021 0 PS26
1
2
3
4
5
6
7
COPYRIGHT © 2001 CANON INC.
Description
print start signal
transmission request signal
controller power supply inlet ready signal
printer power supply inlet signal
not used
not used
not used
not used
BD cycle error signal
phsync cycle error signal
sub scanning select line interrupt signal
image end signal
not used
not used
not used
not used
zero-cross signal
heater trigger 1 signal
heater trigger 2 signal
heater error OFF signal
not used
not used
registration motor phase A pulse signal
registration motor phase B pulse signal
fixing film rotation detection signal
not used
not used
not used
not used
not used
finisher detection signal
saddle finisher detection signal
2000 2000 2000 2000 CANON iR2200/iR2800/iR3300 REV.0 MAR. 2001
CHAPTER 5 SERVICE MODE
COPIER>I/O>DC-CON
Remarks
-
-
-
-
1: present
1: present
-
-
-
0: ON
0: ON
0: error
-
-
-
inner 2-way tray absent:
finisher: bit6=0, bit 7=1
saddle finisher:
bit 6=0, bit 7=0
bit 6=1
5-25 T
