Note: For Tag 1 the Badge number (Tag Code) is disabled as it is Read only, but it is enabled
in the other tags. It will be Read only and the same as the Badge number.
Enter the following for Tag(s):
•
TAG Code: The number of the tag or badge you wish to use. Use the Read Badge
icon to the right of the TAG Code field to enter the number from the Registration Reader
(RR).
•
TAG Type: The choices from the dropdown menu are: Slim Tag (5 bytes), ISO Animal,
WriTag 2048, WriTag 128, ASCII, Barcode, Magstripe, Sagem Biometric, Personal
Access Code, RF/InfraRed Tag, Mifare Tag, HID Tag, Felicia Tag, General 13.56 MHz
Tag, and Any Tag Type. (For AmanoNet only)
•
Group 1 to 3 [for 4 Tag systems] and 1 to 6 [for 8 Tag systems]: Access groups that will
be assigned to the tag.
•
Start Date: The date when the tag will be activated (YYYYMMDD).
•
End Date: Displays the date when the tag will expire (YYYYMMDD). (If left blank, the tag
will never expire).
•
End Time: The actual hour (1 – 23) on the date when the tag will expire (HH).
•
Type: (Tag Options) Assigns one of the following functions to the badge or tag:
a. Normal: Normal employee
b. Suspend: All access for a particular tag is suspended
c. Blacklist: The tag holder will be denied access to the site
d. Special Events, 1 and 2 Button: Tag holders are admitted for specific events, such as
a meeting or demonstration
•
APB Override: Enables the tag holder to override the APB constraint condition on the
doors to which they have access.
•
Report Always: When checked all transactions with this will be reported.
If you wish to assign another tag for the employee, click on the Tag 2, thru Tag 4 (Tag 8)
buttons and follow a similar procedure performed for Tag 1.

Configuring AmanoNet 7.6

The following paragraphs detail the steps involved in integrating data between the Time &
Attendance software and the AmanoNet 7.6 system.
Step A. Configure AmanoNet 7.6 Settings with the following procedure:
1. Login to the Time & Attendance software, select the Setup Wizard from the Edit menu and
the Setup Wizard screen will appear.
2. From the General Tab of the Setup Wizard, select Yes to integrate Access Control, then
click on the Access Control button and the Access Control screen will appear.
3. From the General tab on the Access Control screen;
