EPSON AcuLaser CX11/CX11F

NETWORK SETUP ITEMS

Setup menu Setup items
*1
Network I/F On, Off
*2
Network Config ǵǻǢÅADzÇÈ
*3
Get IPAddress Panel, Auto, Ping
*3, 4 5
IP 0.0.0.0 - 255.255.255.255
*3
SM 0.0.0.0 - 255.255.255.255
GW *3 0.0.0.0 - 255.255.255.255
*3
AppleTalk On, Off
*3
MS Network On, Off
Rendezvous *3 On, Off
*3
Link Speed Auto, 100 Full, 100 Half, 10
Full, 10 Half
Note *1: Only displayed when the network interface board is installed. After this item is
changed, the setting value takes effect after a warm boot or after the power is turned
on again. While it is reflected in the Status Sheet and EJL read-back, the actual
change takes effect after a warm boot or after the power is turned on again.
*2: Only displayed when a network interface board is installed. Changed to "Network
Config=No" automatically when exitting the setup mode.
*3: Only displayed when a network interface board is installed and "Network Config" is
set to Yes.
*4: The actual valid value is displayed (but cannot be changed) when "Get IPAddress =
Auto".
*5: When the "IP Adress" - "Panel" or "PING" is changed to "Auto", the setting value of
the "Panel" or "PING" is memorized and it is restored and displayed on the panel
when the setting is changed back to "Panel" or "PING". The printer displays
"192.168.192.168" if the settings are not made from the panel.
Remarks
---
---
Default values vary according to
the destination.
---
---
---
---
---
---
Default values vary according to
the destination.
1.3.3.2 Fax Mode

BASIC SETUP ITEMS

Setup menu Setup items
Line type PSTN, PBX, FlashStart
Dial type Tone, 10 pps, 20 pps
Personal Number User name and fax number
Speaker volume OFF, 1, 2, 3
Country/Area Set. Austria, Belgium, Denmark,
Finland, France, Germany, Greece,
Holland, Ireland, Italy,
Luxemburg, Portugal, Spain,
Sweden, U.K., Russia, Poland,
Czech, Hungary, Switzerland,
Norway, Argentine, Brazil,
Mexico, Taiwan, China, Korea,
Hong Kong, Singapore, Australia,
New Zealand, Thailand, Malaysia,
U.S.A., Canada
Report printing Setup English, Francais, Deutsch,
Italiano, Espanol, SVENSKA,
Dansk, Nederlands, SUOMI,
Portugues, ,
Note *: Fax basic settings cannot be changed as long as there are jobs stored in the memory.

TRANSMISSION SETUP ITEMS

Setup menu Setup items
Auto Redial Tries 0 - 99
Print Sender Info. On, Off
Note *: Fax transmission settings cannot be changed as long as there are jobs stored in the
memory.
Revision B
Remarks
FlashStart is only available in
Germany and France.
Adds the FlashStart function to
PBX to support FlashStart
When the country setting is set to
Australia, "20 pps" is not displayed.
Numbers: 20 digits, names: 32
characters, name can only be set
with the tool.
4 levels
---
Default values vary according to
the country setting.
Remarks
Times
It set to 14 times in Australia, and it
set to 9 times in New Zealand.
---
67
