EPSON AcuLaser CX11/CX11F

FIP-N2 At Standby

Possible parts that caused the error
MOT ASY FSR
2ND BTR ASSY
Troubleshooting
Step Check
Is abnormal noise being generated from
1
MOT ASSY FSR?
(It rotates when the temperature of FUSER
ASSY reaches the specified value)
Is abnormal noise being generated by
2
FUSER ROLL in FUSER ASSY that is
driven by MOT ASSY FSR?
Is abnormal noise being generated from 2ND
3
BTR ASSY that is driven by MOT ASSY
FSR?
TROUBLESHOOTING
FUSER ASSY
Yes No
Replace MOT Go to Step [2].
ASSY FSR.
Clean or replace Go to Step [3].
FUSER ROLL.
Clean or replace
2ND BTR
ASSY.
