EPSON AcuLaser CX11/CX11F

1.1 Overview

The AcuLaser CX11/CX11F are all-in-one host- based color laser printers, which
include scan, copy, and fax functions. (The AcuLaser CX11 does not have the fax
function.)
A4 full-color 4-cycle engine, which is the same as AcuLaser C1100, is employed. Both
of the two models have a control panel with a large LCD. As the control panel is
independently-designed for each model; AcuLaser CX11 (fax-UNinstalled model) and
AcuLaser CX11F (fax installed model), changing CX11 to CX11F or the reverse is not
available.

1.1.1 Printer Section

Compact and lightweight engine, which enables True 600 dpi
Print Speed
Color : 5.0 PPM (for A4 printing)
Monochrome : 25.0 PPM (for A4 printing)
Manual duplex printing supported
Paper Feeder Capacity
MP cassette : 200 sheets (paper basic weight is 64g/m
Optional lower cassette : 500 sheets (paper basic weight is 64g/m
Paper Eject Capacity
Face-down : 250 sheets
NOTE: Conditions for the capacity:
22 degrees C/55% RH, standard paper (simplex/duplex printing).
The print ratio is 5% for both B/W and color printing (With color
printing, 5% for each color)
Consumables
Toner Cartridge with CSIC chip (C, M, Y, K)
Photoconductor Unit with CSIC chip
(Transfer Belt and Waste Toner Box are included)

1.1.2 Scanner Section

Color CCD
A4 compatible flatbed scanner with optical resolution of 600 dpi
Scan Speed
Color
Monochrome
Auto Document Feeder (ADF)
Capable of loading up to 50 sheets (paper basic weight is 80g/m
(Fax model only)

1.1.3 Fax Section

High-speed operation suitable for business purposes
Super G3 compatible
Communication Speed
Supports both PSTN and PBX
Improved usability suitable for business purposes
2
)
One-touch send button
2
)
Speed dial
Group dial
Conforms to Color FAX standards
Conforms to Communication standards for each country
Supported countries
manuals4you.com manuals4you.com
: 5.0 PPM (for A4 size)
: 25.0 PPM (for A4 size)
2
).
: 2.4K to 33.6Kbps
: 3 buttons
: Up to 60 entries
: Up to 20 groups
: 36 countries
Revision B
