Name
1 NET MGT 10/100
Ethernet LED
2,3,4 GigabitEthernet LED Green and
5 Server Locate LED
6 Server Service Action
Required LED
7 Power OK LED
10/100 Ethernet LED Activity Table
TABLE 1
LED Name Color
10/100 Ethernet Green
(right side)
Amber
10/100 Ethernet Green
(left side)
Color Activity
Green and See Table 1
Amber
See Table 2
Amber
White Use to identify a server in a rack. Activate locally by pressing the
Locate button or activate remotely using the ILOM.
■
Off: Normal
■ On: Blinking
Amber The SP monitors the health of the system and activates the
Service Action Required LED.
■
Off: Normal operation.
■
Slow blink: A new (unacknowledged) event that requires a
service action has been detected.
■
Steady on: An event has been acknowledged, but the
problem still requires attention.
The following conditions cause the SP to activate the Service
Action Required LED:
■
Voltage outside thresholds
■
Temperature above thresholds
■
Fan speed below thresholds (or not present)
■ 24 correctable errors have occurred in a 24 hour period.
■
One correctable error has occurred.
Green Use to discern the power state of the server.
■
Steady On: Full-power mode on and OK.
■
Blinking: Standby power is on, but main power is off
■
Quick blink: in POST, diagnostics running
■
Off: No power. AC cords not attached.
Activity
On: Link established at 100 Megabits.
On: Link established at 10 Megabits. Amber LED indicates that
the link established is not at full capacity for that port.
On: Link Activity.
Rear Panel System Status LEDs
