Rear Panel Features and Components
See also:
"Locations of Internal Server Components" on page 30
■
"Front Panel System Status LEDs" on page 78
■
Next:"Rear Panel Features and Components" on page 16
Rear Panel Features and Components
Legend
1
3
5
7
9
11 PCIe slot (Gen 2, x16)
See also:
"Locations of Internal Server Components" on page 30
■
"Rear Panel System Status LEDs" on page 80
■
"Front Panel Features and Components" on page 15
■
16 Sun Fire X2270 M2 Server Service Manual • January, 2012, –12
AC power connector
Amber Service Action Required LED
Serial Management (SER MGT) port (RJ-45) 6
GigabitEthernet port (NET-1)
Network Management (NET MGT)
Ethernet port (available only in systems with
an SP module)
2 White Locate LED
4 Green Power Status LED
GigabitEthernet port (NET-0)
8 USB 2.0 ports (2)
10 HD-15 video connector (available only in systems
with an SP module)
