Tools and Supplies Needed

Component
HD backplane
Front I/O board
DIMM
Power Supply 600 W
Hard drive
Solid-state drive
Slide rail kit
Tool-less slide rail kit
Cable management arm
Service processor module
SATA cable
Blower assembly
Battery (CR2032)
Front I/O cable kit
Riser card, PCIe x16 slot
Next:"Tools and Supplies Needed" on page 20
Tools and Supplies Needed
You need the following tools and supplies to perform Sun Fire X2270 M2 Server maintenance
procedures:
#2 Phillips screwdriver (6 inches)
■
Small flat-blade screwdriver
■
Antistatic wrist strap
■
Portable light source
■
Antistatic brush, canned air, or a vacuum cleaner (to remove dust and debris)
■
Alcohol pads (for CPU replacement by service personnel only)
■
Next:"How to Prepare for Service" on page 21
20 Sun Fire X2270 M2 Server Service Manual • January, 2012, –12
Designation
FRU
FRU
CRU
CRU
CRU
CRU
CRU
CRU
CRU
CRU
CRU
CRU
CRU
CRU
CRU
