Oracle Sun Fire X2270 M2 Service Manual page 35

▼
How to Install a DIMM
Tip –
install it.
See:
Before You Begin
"Locations of Internal Server Components" on page 30
■
"DIMM Population Rules" on page 38
■
"DIMM Slot Designations" on page 37
■
Prepare the server for service. See
1
Remove the air duct. See
2
Locate the DIMM socket in which you want to install or replace a memory module. For slot
3
designations, see
Ensure that the DIMM socket ejector levers are open (rotated fully outward).
4
Align the notch in the DIMM's edge connector with the socket alignment key.
5
Ensure that the DIMM's edge connector is positioned correctly within the slot.
6
To install the DIMM, simultaneously press downward on both top edges of the DIMM until the
7
ejector levers rise to their vertical position and lock into place.
This action produces a click as the levers lock the DIMM in the slot.
Note –
As an ESD precaution, do not remove the DIMM from its packaging until you are ready to
"How to Remove the Air Duct"on page
"DIMM Slot Designations"on page
Insert the DIMMs evenly, straight down along the DIMM slot until locked into place.
"How to Prepare for Service"on page
37.
Removing and Installing DIMMs (CRU)
21.
53.
35
