Oracle Sun Fire X2270 M2 Service Manual page 12

Components List
Component and Feature
Memory
Disk and Storage
Power Supply
Network I/O
PCI I/O
External I/O
12 Sun Fire X2270 M2 Server Service Manual • January, 2012, –12
■
Up to 96 GB of DDR3-1066
■
Up to 96 GB of DDR3–1333
■ SATA hard drive (HD)
■
SATA solid-state drive (SSD)
■
Embedded RAID support
600W PSU, 80% high-efficiency
■
Two 10/100/1000BASE-T
GigabitEthernet ports
■ One 10/100BASE-T Network
Management (NET MGT)
Ethernet port
PCI Express Generation 2
Serial/RJ-45 and USB 2.0
■
Twelve DDR3-1333 capable
DIMM slots (6 DIMM per
CPU) that support up to 96 GB
maximum using 8 GB 1066
MHz DIMMs.
■
Each DIMM socket can
support a 8 GB 1333 MHz, or 8
GB 1066 MHz registered
DIMM module.
■ Supports four 3.5" 2 TB 7.2K
RPM SATA disk drives.
■
Supports four 2.5" 32 GB SSD
drives.
■
Up to 8 TB with 3.5" SATA
drives
■
Up to 128 GB with 2.5" SSD
drives
■
Embedded controller Supports
RAID 0,1,5 & 10 on Windows
Only
■
One PCI Express 2.0 slot
■
50 W max, x16 slot
electrical/mechanical, x16 90
degree angle PCIe riser
■
One RJ-45 serial port
■
Five USB 2.0 ports (2 front, 2
rear, and 1 internal)
