Removing, Installing, and Adding a CPU and Heatsink
(FRU)
Note –
certified Oracle Service Technician.
The following procedure describes how to replace a CPU. The Sun Fire X2270 M2 Server
supports both single-CPU and dual-CPU configurations. The procedures in this section include
removal and installation procedures, as well as a procedure for adding a second CPU to a
single-CPU configuration.
"How to Remove a CPU and Heatsink" on page 67
■
"How to Install a CPU and Heatsink" on page 68
■
"How to Add a New CPU and Heatsink Assembly" on page 70
■
▼
How to Remove a CPU and Heatsink
See:
Before You Begin
"Locations of Internal Server Components" on page 30
Prepare the server for service. See
1
Remove the air duct. See
2
Remove the four screws that secure the heatsink to the motherboard.
3
Slightly wiggle the heatsink right and left to break the seal created by the thermal compound.
4
Lift the heatsink away from the CPU and out of the server.
5
The CPU and heatsink assembly is a field-replaceable unit. It must be replaced by a
"How to Remove the Air Duct"on page
Removing, Installing, and Adding a CPU and Heatsink (FRU)
"How to Prepare for Service"on page 21.
53.
