Insert the new system battery into the battery holder with the side labeled"+"facing upward.
4
Note –
Install the air duct. See
5
Prepare the server for operation. See
6
Removing and Installing DIMMs (CRU)
This section contains the following topics:
"How to Remove a DIMM" on page 33
■
"How to Install a DIMM" on page 35
■
"Error Correction and Parity" on page 36
■
"DIMM Slot Designations" on page 37
■
"DIMM Population Rules" on page 38
■
▼
How to Remove a DIMM
See:
Before You Begin
"Locations of Internal Server Components" on page 30
Prepare the server for service. See
1
Replace the battery only with the identical model.
"How to Install the Air Duct"on page
"How to Prepare for Operation"on page
"How to Prepare for Service"on page
Removing and Installing DIMMs (CRU)
53.
26.
21.
