Oracle Sun Fire X2270 M2 Service Manual page 55

Prepare the server for service. See
1
Remove the air duct. See
2
Unplug the blower's power connector from the motherboard.
3
Pull the blower upward while pushing the connector cable through the cutout in the chassis
4
divider and taking care not to catch the connector on the metal, to remove the blower from the
chassis.
Caution –
components installed.
"How to Install a Blower Module" on page 55
See Also ■
▼
How to Install a Blower Module
See:
Before You Begin
"Locations of Internal Server Components" on page 30
■
"Sun Fire X2270 M2 Server Internal Cabling" on page 61
■
"How to Remove the Air Duct"on page
Thermal over-temperature potential. Do not operate the server without all airflow
"How to Prepare for Service"on page
Replacing a Blower Module (CRU)
21.
53.
55
