Removing and Installing a Hard Drive Filler and Hard Drive Assembly (CRU)
Slide the filler into the vacant slot until the front of the filler is flush with the front of the server.
3
Close the latch and rotate the release lever to lock the latch.
4
"How to Remove a Hard Drive Filler" on page 48
See Also ■
"How To Remove a Removable Hard Drive Assembly" on page 50
■
"How to Install a Removable Hard Drive Assembly" on page 51
■
▼
How To Remove a Removable Hard Drive Assembly
Caution –
populated with either a drive or a filler panel.
Power off the server. See
1
Note –
the server before removing a hard drive.
On the drive you want to remove, push the release button to open the latch and extend the latch
2
to its fully-open position.
Note –
latch.
50 Sun Fire X2270 M2 Server Service Manual • January, 2012, –12
Thermal over-temperature potential. Do not operate the server without all drive slots
"How to Power Off the Server"on page
If you are using an integrated-mirroring (IM) configuration, you do not need to power off
The latch is not an ejector. Do not bend it too far to the right. Doing so may damage the
28.
