Appendix A: Cable Pinout Assignments

Audio

188
Table A-6 (continued)
Pin Assignment
41 ATN
42 GROUND
43 BSY
44 ACK
45 RST
46 MSG
47 SEL
48 C/D
49 REQ
50 I/O
Table A-7 shows the cable pinout assignments for the audio ports.
Table A-7 Audio Ports
Connector
Digital Input/Output
Headphone Output
Line Output
Line Input
Microphone Input
SCSI Port
Tip Ring
Out In
L R
L R
L R
L R
Sleeve
GROUND
GROUND
GROUND
GROUND
GROUND
