4. Install the new CPU module.
The CPU module on your workstation may look different than the one shown
Note:
in Figure 6-25.
Position the new module so the connector on the bottom of the module aligns
with the socket on the board, as shown in Figure 6-25.
Press down on top of the module connector until it is securely attached to the
socket on the board.
Replace the four screws.
Figure 6-25 Installing the CPU Module
Ordering, Removing and Installing Parts
147
