Chapter 6: Troubleshooting

Ordering, Removing and Installing Parts

134
This system is designed so that you can maintain it. If diagnostic tests identify a faulty
part, you must order a replacement part, remove the faulty part, and install a
replacement part. Contact your service organization before removing the faulty part.
Parts are available to users from authorized service organizations. Figure 6-11 shows the
names and locations of each user-replaceable part inside the system.
Graphics
Board
CPU
Board
Figure 6-11 Replaceable Indigo Parts
Power
Supply
Drive
Slots
