Adding SIMMs to the IRIS Indigo Workstation

Installing the SIMMs in an IRIS Indigo R4000 Family Workstation

To install the SIMMs in IRIS Indigo R4000 family workstation, remove the SIMMs from
the anti-static bag and follow these steps:
1. Install the first SIMM.
Orient yourself to the CPU board, as shown in Figure 3-8.
Orienting Yourself to the CPU Board
Figure 3-8
49
