Chapter 3: Installing Memory
60
3. Loosen and remove the SIMMs.
Locate the memory SIMMs you want to remove.
Look for the white lever on the right side of the memory socket.
Grasp the SIMM removal tool by the handle.
Slip the notched edge of the removal tool under the white lever on the right side
of the SIMM socket, as shown in Figure 3-22.
Pull straight up to lift one side of the SIMM free from the socket contacts. The
SIMM is tightly seated, so this may take considerable force.
Figure 3-22 Removing the SIMM Using the SIMM Removal Tool
