Chapter 2: Getting Started

Putting the Pieces Together

16
To put your IRIS Indigo workstation together, you must install the system disk drive and
any other drives into the chassis before connecting the monitor, keyboard, and mouse.
Finally, after you've connected all the cables and installed the drives, you must plug the
workstation in and turn it on.
Place the monitor and the IRIS Indigo chassis near the site you selected. Then follow
these steps:
1. Remove the front plastic cover of the chassis.
Face the front of the chassis.
Two tabs on top of the front cover hold it in place.
Press down on the tabs and pull the cover away, as shown in Figure 2-4.
Figure 2-4 Removing the Front Cover of the IRIS Indigo Chassis
